Key Features

HDBaseT via Single CAT5e/6 UTP/STP Extension: With fully automatic adjustment of feedback,
›
equalization, and amplification depending on cabling length
Power over HDBaseT: Tx unit powers Rx unit . Only one power connection needed .
›
Signal Extension:
›
Up to 150 ft. @ 4K 24/25/30(4:4:4)/60(4:2:0) using CAT6A cabling
»
Up to 125 ft. @ 4K 24/25/30(4:4:4)/60(4:2:0) using CAT5e/6 UTP/STP cabling
»
Up to 250 ft. @ 1080p / 1920x1200 using CAT6A cabling
»
Up to 230 ft. @ 1080p / 1920x1200 using third-party CAT5e/6 UTP/STP cabling
»
HDCP 2.2: Compliancy up to HDCP 2 .2 and backward compliant
›
HDR (High Dynamic Range): HDR is achieved with AppleTV source at 4K/30 [4:2:2] 12bit deep
›
color, enabling more life-like images through a greater range of luminance levels .
4K/Ultra HD Resolution: Supports signals up to 4096x2160 60Hz [4:2:0] 8bit, 4096x2160 30Hz
›
[4:2:2] 12bit, and 4096x2160 30Hz [4:4:4] 8bit
Deep Color Support: Up to UHD/4K 30Hz 4:2:2/12 bits or 60Hz 4:2:0/8 bit
›
Low Profile: Super slim chassis design
›
HDMI and HDCP Licensing: Fully licensed and compatible with HDCP 2 .2 and HDMI latest
®
›
technology such as 4K/UHD 4:2:0/8bit at 60f/s
EDID Control: Internal library features 15 default EDID configurations and native EDID data from
›
Output/Display devices connected via Rx
Hot Plug Detection Control: Enables integrator to choose if active signal voltage is forced to
›
connected input devices
Full Buffer System
›
with source & display, EDID Control handshake, and Hot Plug control
IR Sensor: Sensor powering via +5V on Rx unit's IR In port collects line-of-sight IR from remote(s)
›
without external IR connecting block
Up/Down IR: Two channels of IR enable control to/from devices connected to Tx and Rx units
›
RS-232: Bi-Directional control to/from Tx and Rx unit on Phoenix connector
›
Rotary Switch RS-232 Control Mode: Provides control of Tx unit as well as connectivity status
›
3D: Support for standard 3D stereoscopic signal formats
›
Surround Sound Audio: Supports Dolby
›
Master Audio multi-channel audio formats
™
CEC Support: For inter-device control between input and output HDMI channel
›
I2C Communication: EDID and HDCP authentication to Display and Source
›
Control System Support: Fully controllable by all RS-232 supported control systems via open API:
›
Compass Control , AMX
®
: Manages TMDS re-clocking / signal re-generation, HDCP authentication
™
®
, Crestron , KNX
® ® ®
TrueHD, Dolby Digital Plus, Dolby Atmos
®
, RTI , Savant, URC , Leviton
® ®
, and DTS-HD
®
etc .
®
