Summary of Contents for Key Digital KD-X444LP
- Page 1 KD-X444LP 4K 18G HDMI over 70m CAT5e/6 Extender Set with HDR, Power over Cat, HDMI Pass Thru, IR or RS-232 Engineered for Your Success ™ Quick Setup Guide...
-
Page 2: Table Of Contents
› AV Receivers. brand new AV signal In addition to HDMI AV, KD-X444LP carries IR or RS-232 for controlling remotely located equipment. Surround Audio Support: On HDMI pass-thru and UHDoTP outputs: › An IR sensor and IR emitter are included with the IR Input port also supporting Serial IR input HDMI Pass-Thru: Supports Dolby ®... -
Page 3: Application Example
3. Connect your HDMI display to the output port of the Rx unit 4. Connect your local monitor / AV Receiver to the HDMI pass-through port of the Tx unit KD-X444LP Tx 5. Connect a CAT5e/6 cable between Tx and Rx unit. Use 568-B termination. - Page 4 “F/W Load” should only be selected if loading firmware to the unit. › 4Kx2K@60, 10.2G, HDR, HD AUDIO Firmware load/upgrade should only be done if advised by Key Digital Technical Support » 4Kx2K@60, 18G, HDR, 2CH AUDIO Forced HPD Switch (Rx Unit) 4Kx2K@60, 18G, HDR, DOLBY/DTS 5.1...
-
Page 5: Contacting Key Digital
Power Supply Use: Tx Pass-Through: Solid illumination from active Hot Plug Detection voltage with connected » You MUST use the Power Supply PROVIDED with your unit or you VOID the Key Digital ® display/output device Warranty and risk damage to your unit and associated equipment. - Page 7 , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high-end video and control are important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
