Table Of Contents - Key Digital KD-X222PO Operating Instructions Manual

2

Table of Contents

Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Quick Setup Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Application Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Extending IR or RS-232 Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
LED Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
RS-232 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Always follow the instructions provided in this Operating Manual.
Please visit www.keydigital.com
downloads. Product features and specifications are subject to change without notice.
Introduction
Key Digital KD-X222PO HDBaseT/HDMI (Tx + Rx) Extenders are an HDCP 2 .2 compliant product that
®
extend 4K/UHD 24/25/30 (4:4:4) and 4K/UHD 60 (4:2:0) signals up to 150 ft . using CAT6A cable, or
up to 125 ft . using a CAT5e/6 cable . 1080p/60, 1920x1200, 3D signals are extended up to 250 ft .
via CAT6A cable, or up to 230 ft . using a CAT5e/6 cable . In addition to HDMI video and audio signals,
KD-X222PO carries IR or RS-232 for controlling remotely located equipment or the RS-232 port can
be used to control the KD-X222PO .
for the latest product documentation and software
