KD-X611ProK
HDBaseT/HDMI via Single CAT5e/6 (Tx+Rx Set) Extenders
with Audio De-embedding, EDID Control, Hot Plug Control,
Long Range Mode, Full Buffer System, HDMI Pass-through,
Ethernet, IR Sensor, Up/Down IR & RS-232,
support Ultra HD/4K & HDCP2.2
Operating Instructions
The Experts in Digital Video Technology and Solutions
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Key Digital FatCat Series
Summary of Contents for Key Digital FatCat Series
- Page 1 , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high-end video and control are important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
-
Page 2: Table Of Contents
Installation and Operation ......... . . 3 signals are extended up to 600 ft. with Long Range Mode via single Key Digital ®... -
Page 3: Quick Setup Guide
You MUST use the Power Supply provided with your unit or you VoID Control System Support: Compatible with Compass Control , AMX ® ® ➔ the Key Digital Warranty and risk damage to your unit and associated ® Control4 ® , Crestron ®... -
Page 4: Application Examples
Application Examples iPad Full Extension Capabilities Example - Ultra HD/4K HDMI WiFi WiFi Local Router Display HDMI 4K up to Satellite 300’ with Key Digital IR Out KD-X611ProK KD-CAT6STP1X RS-232 CAT5e/6 Display KD-MC1000 EDID Control RS-232 HDMI RJ45 Master Controller... - Page 5 Display HDMI HDMI 20’ 20’ HDMI HDMI KD-X611ProK KD-X611ProK Satellite Red Ray CAT5e/6 CAT5e/6 300’ 600’ Up to with Key Digital KD-CAT6STP1X Up to with Key Digital KD-CAT6STP1X ® ® Pass-through Pass-through Display Display HDMI HDMI 20’ 20’ KD-X611ProK KD-X611ProK...
-
Page 6: Connections
Connections Use the 3.5mm analog audio and/or PCM coaxial digital audio de-embed ports to ➔ integrate with audio distribution systems, amplifiers, or AV receivers. Before making any connections, power off your source and display devices. Tx Unit: Using a short HDMI cable, connect your source device to the HDMI port labeled ➔... -
Page 7: Audio De-Embedding Outputs
Rx Unit: After all the connections are made, connect power to the Tx and Rx ➔ units using the included power supplies and then power up your source Using a short HDMI cable, connect your output / display device to the HDMI port ➔... -
Page 8: Extending Ir Or Rs-232 Control
RS-232 Cabling Bi-directional IR control extension is supported. 3.5mm stereo to RS-232 adapter cables are available through Key Digital and other » “IR In” port on the Tx unit extends to the “IR Out” port of the Rx unit wire suppliers, and can also be fabricated by skilled technicians. - Page 9 » Rx Unit / IR Sensor: » IR Sensors can be connected directly into the Rx unit’s IR In port, without The included blinking-type IR Emitter. the need for an external IR distribution block The 3.5mm connector is mono and it connects to »...
-
Page 10: Settings
Settings Control Rotary The Control rotary enables the integrator to choose the EDID Control desired setting for RS-232 Mode and Hot Plug Detection EDID authentication is provided from the KD-X611ProK Tx unit to the connected Control, and Extension Mode. input / source device. The EDID file (AKA “handshake”) is selected using the EDID In many settings, the Control rotary setting may not match on Control rotary on the Tx unit and provides a list of compatible video and audio the Tx and Rx units. -
Page 11: Led Indicator Lights
Hot Plug Detection Extension Mode NoTE: Use shielded metal RJ45 connectors with Control soldered ground wires when terminating shielded CAT5e/6. Key Digital part: KD-RJ45SC (compatible Firmware Upgrade for MCU Forced HPD On Standard with KD-CAT6STP1X and other third-party CAT6/STP) Firmware Upgrade for MCU... -
Page 12: Rs-232 Commands
Data Bits = 8 ➔ Stop Bits = 1 KD-X611ProK> STA ➔ Ground Parity = None ➔ ------------------------------------------------------------------------- Key Digital Systems STATUS Flow Control = None ➔ ------------------------------------------------------------------------- Carriage Return: Required ➔ -- KD-X611ProK System Address : 00 F/W Version : 1.00 Line Feed: Required ➔... -
Page 13: Specifications
Accessories: (2) Mounting Brackets, (1) IR Emitter, (1) IR Sensor » Exposure to rain or moisture ➔ Power Supply Use: You MUST use the Power Supply provided with your unit or you VOID the Key Digital Warranty and risk damage to your unit and associated ® equipment. -
Page 14: How To Contact Key Digital
® System Design Group (SDG) standards and should provide years of trouble-free operation. For system design questions please contact us at: They are backed by a Key Digital Limited 10 Year Product Phone: 914-667-9700 ➔ Warranty Policy.
