OLIMEX© 2012
2) Download and install the latest version of "Atmel Flip" software (it can be downloaded from the
Atmel's web-site)
3) Open its install folder and update the software of the unrecognized device (usually under "Other
devices" tab) with the drivers from folder named "usb"; the device should now be recognized as
AT90USB162 under "libusb-win32" tab
4) Start "Atmel FLIP" and click "Select a target device" -> choose AT90USB162
5) Click "Select a Communication Medium" and then USB medium
6) From "File -> load HEX file" choose this HEX
in the "Operations Flow" section
7) Disconnect the AVR-ISP-MK2 from the USB and connect it again
Please refer to 4.2 Arduino, AVRDude, Linux for more detailed description.

5.3 Jumpers description

Please note that the two jumpers on the board are PTH (plated-through hole) type and should be
easy to mount/dismount.

5.3.1 TARGET jumper

TARGET jumper controls the powering of the target board. If it is in position ON (check the
diagram on the back of the plastic cover) it will provide either 3.3V or 5V to the target board
(depending on the position of the POWER jumper)
The default position is OFF.

5.3.2 POWER jumper

If you have set the TARGET jumper to position ON POWER jumper controls whether 3.3V or 5V
are provided to the target board.
The maximum amperage available for both 3.3V and 5V modes is 300mA.
The default position is 5V.
(CLICK FOR
Page 14 of 19
AVR-ISP-MK2 user's manual
DOWNLOAD) and click "RUN"
