- Page 1 PROCESS AUTOMATION SAFETY MANUAL SIL Relay Module KFD0-RSH-1(-Y2), KFD2-SL-4 ISO9001...
- Page 2 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation...
-
Page 3: Table Of Contents
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Contents 1 Introduction ................ 4 General Information ..................4 Intended Use ....................4 Manufacturer Information................5 Relevant Standards and Directives...............5 2 Planning ................6 System Structure ..................6 Assumptions ....................7 Safety Function and Safe State..............8 Characteristic Safety Values .................9 3 Safety Recommendation .......... -
Page 4: Introduction
(which lead to faults or affect the safety functions), can damage property and the environment or cause personal injury, for which Pepperl+Fuchs GmbH accepts no liability. The devices have been developed, manufactured, and tested according to the applicable safety standards. -
Page 5: Manufacturer Information
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Introduction KFD2-SL-4 The devices are 4-channel signal conditioners with outputs that switch up to 600 mA to high-power solenoids. The devices are also used as power amplifier up to a switching frequency of 1 kHz. -
Page 6: Planning
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Planning Planning System Structure 2.1.1 Low Demand Mode of Operation If there are two loops, one for the standard operation and another one for the functional safety, then usually the demand rate for the safety loop is assumed to be less than once per year. -
Page 7: Assumptions
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Planning Assumptions The following assumptions have been made during the FMEDA analysis: The device shall claim less than 10 % of the total failure budget for a SIL2 safety loop. For a SIL2 application operating in Low Demand Mode the total PFD value ... -
Page 8: Safety Function And Safe State
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Planning It is assumed that any safe failures that occur (e.g., output in safe condition) will be corrected within eight hours (e.g., correction of a sensor fault). While the device is being repaired, measures must be taken to maintain the ... -
Page 9: Characteristic Safety Values
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Planning Characteristic Safety Values KFD0-RSH-1 Parameters acc. to IEC 61508 Values Assessment type and documentation FMEDA report Device type Mode of operation Low Demand Mode or High Demand Mode Safety function Output relay in OFF state when input is de- energized 251.6 FIT... - Page 10 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Planning KFD0-RSH-1-Y2 Parameters acc. to IEC 61508 Values Assessment type and documentation FMEDA report Device type Mode of operation Low Demand Mode or High Demand Mode Safety function Output relay in OFF state when input is de-...
- Page 11 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Planning KFD2-SL-4 Parameters acc. to IEC 61508 Values Assessment type and documentation FMEDA report Device type Demand mode Low Demand Mode or High Demand Mode Safety function Outputs de-energized when common disable input is de-energized + ...
-
Page 12: Safety Recommendation
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Safety Recommendation Safety Recommendation Interfaces The device has the following interfaces. For corresponding terminals see data sheet. Safety relevant interfaces: KFD0-RSH-1(-Y2): input, output KFD2-SL-4: inputs, outputs, common disable input Configuration KFD0-RSH-1(-Y2) A configuration of the device is not necessary and not possible. -
Page 13: Installation And Commissioning
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Safety Recommendation Our experience has shown that the useful life time of a Pepperl+Fuchs product can be higher if there are no components with reduced life time in the safety path (like electrolytic capacitors, relays, flash memory, opto coupler) which can produce dangerous undetected failures and if the ambient temperature is significantly below 60 °C. -
Page 14: Proof Test
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Proof Test Proof Test Proof Test Procedure According to IEC 61508-2 a recurring proof test shall be undertaken to reveal potential dangerous failures that are otherwise not detected by diagnostic test. The functionality of the subsystem must be verified at periodic intervals... - Page 15 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Proof Test Procedure For the proof test the tests have to be done as shown in the following tables and pictures. Test each separate channel that is used in the safety function application and the respective safety path.
- Page 16 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Proof Test Within the test, the switches are used. The correct settings for the application must be established again subsequent to the test. KFD2-SL-4 Test No. Procedure Input and common disable Output output Attach the input voltage subsequently...
-
Page 17: Abbreviations
Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Abbreviations Abbreviations Distributed Control System Emergency Shutdown Failure In Time in 10 FMEDA Failure Mode, Effects and Diagnostics Analysis Probability of safe failure Probability of dangerous detected failure Probability of dangerous undetected failure ... - Page 18 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Notes...
- Page 19 Safety Manual SIL KFD0-RSH-1(-Y2), KFD2-SL-4 Notes...
- Page 20 PROCESS AUTOMATION – PROTECTING YOUR PROCESS Worldwide Headquarters Pepperl+Fuchs GmbH 68307 Mannheim · Germany Tel. +49 621 776-0 E-mail: info@de.pepperl-fuchs.com For the Pepperl+Fuchs representative closest to you check www.pepperl-fuchs.com/contact www.pepperl-fuchs.com Subject to modifications Copyright PEPPERL+FUCHS • Printed in Germany DOCT-2867A 07/2014...
