Tape Application Monitor (TAM)
Figure 6-2
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
TAM Application Monitor - Yype 21800
Page 45
44-0009-2048-6 / ECO# 0078483
3M Part No.
78-8133-9680-7
78-8133-9699-7
78-8133-9682-3
78-8133-9685-6
78-8137-0004-1
26-1016-2509-8
26-1016-2494-3
26-1016-2466-1
26-1000-0010-3
26-1016-2496-8
26-1014-8755-6
12-7990-7756-0
78-8133-9679-9
78-8137-0020-6
26-1014-8756-4
Description
Assembly - Arm Swing
Bracket - Mount Lower
Bracket - Hold Sensor
Shaft - Spacer Pivot
Spring - Torsion L/H
Capscrew - Hex Soc Dr. M4 X 0.7 X 12mm Lg A/Stl Zn Plt
Nut - Loc Hex, Nylon Insert Steel, 1/4-20 A/Stl Zn Plt
Sensor - Prox NPN 2mm M8 Omron E2A-S08KS02-M5-C1
Washer - Plain, A/Stl. Narrow, M6
Washer - Plain, A/Stl. Narrow, M4
Capscrew - Hex Hd. M6 X 1.0 X 16mm Lg., Stl Zn Plt
Screw - Shoulder Hex Soc Dr. 5/16 Dia X .62 Lg., A/Stl
Plate - Nut
Template
Capscrew - Hex Soc Dr. M6 X 1.0 X 20mm Lg., A/Stl Zn Plt
North American - ENG
Date Released:
05-22-18
