7. Spare Parts

Drawing No.: 2924-1000 Vortex compact, 120 V, 60 Hz
Drawing date: 09.06.97
1
3
4
5
6a
ITEM No. DESIGNATION
1 Complete rotary knob
2 Complete rotary knob for
potentiometer
3 Seal ring
4 Filter element
5 Bag-type filter
When ordering spare parts, always quote the drawing number and drawing date.
Status: 09.06.97
6
6b
8
5x
ITEM No. DESIGNATION
6 Suction hose assembly,
3 metres
6a Nozzle-side sleeve DN 36
6b Pivot sleeve DN 36
7 Wheel assembly
8 Steering casters
2
7
8
