USB-NX2-LOCAL-1G/USB-NX2-REMOTE-1G
USB over Network Wall Plates with Routing
For macOS Software:
1. Open System Profiler.
2. In the left column under Hardware, select USB.
3. Check to see if the extender system appears in the USB Device Tree at
the top right of the System Profiler window. If the extender system
has been properly installed, it is listed as a "Hub" under the USB High-
Speed Bus/USB Bus node.
If the USB endpoint system does not detect correctly or fails to detect,
refer to Troubleshoot the USB Endpoint.
Program the USB Endpoint
Program the USB endpoint using the USB-NX2 Module in the Crestron
Studio® application or SIMPL Windows.
Pair the USB Endpoint (Optional)
Pairing the USB endpoint establishes a link between the
USB-NX2-LOCAL-1G and USB-NX2-REMOTE-1G. Manual pairing may be
performed when a USB-NX2-LOCAL-1G and a USB-NX2-REMOTE-1G
are directly connected to each other in a point-to-point configuration or
connected over the Network for multipoint connections. In a
point-to-point configuration, USB switching is not performed. In a
configuration in which USB switching is to be performed, SIMPL
programming automatically pairs the extenders.
Pair a USB-NX2-LOCAL-1G to a USB-NX2-REMOTE-1G.
1. Ensure that the USB-NX2-LOCAL-1G is directly connected to the
USB-NX2-REMOTE-1G.
2. On the USB-NX2-LOCAL-1G, press and hold the PAIR button for less
than 10 seconds. The LINK LED on the front panel of the endpoint
starts flashing green fast, indicating that the endpoint is in Pairing
mode.
NOTE: Press and hold the PAIR button a second time for less than
10 seconds to cancel Pairing mode.
3. Within 10 minutes of activating Pairing mode on the
USB-NX2-LOCAL-1G, press and hold the PAIR button on the
USB-NX2-REMOTE-1G for less than 10 seconds. The LINK LED on the
endpoint starts flashing green, indicating that the unit is in Pairing
mode.
NOTE: Press and hold the PAIR button a second time for less than
10 seconds to cancel Pairing mode.
4. Observe that the LINK LEDs on both endpoints may start flashing
slowly before turning solid green. Once the LINK LEDs are solid green,
a valid link is established between both endpoints.
NOTE: If more than 10 minutes pass and the endpoints are not yet
paired, the endpoints switch back to the regular mode of operation
and reestablish the previous links they had (if any).
Unpair a USB Endpoint
If pairing must be removed from an endpoint, press and hold the PAIR
button for more than 10 seconds.
