Controller Input And Outputs
fi g
01
08
07
Light Relay Output N/O, Com, N/C Contact
01
Lock Relay Output N/O, Com, N/C Contact
02
Serial Interface Connector
03
12 volts 6 Amp - Hr Batteries
04
Engage/Disengagement Handle
05
Standby Battery Charger/Solar Connector
06
Solar Shunt
07
GDO-10V2L2 Toro
8
09
™ Owner Installation Instructions
11
10
06
Standby Battery Shunt
08
Motor Connector
09
10 Amps Slow Blow Fuse
10
24 Volts Ac In Connector
11
Position Sensor Connector
12
05
12
01
02
03
04
