Blue Clean AR 2N1-Q Assembly, Care And Use Instructions page 10

ASSEMBLY INSTRUCTIONS
14
N
Pull back on the collar at the other end of the high
pressure hose (N). Push the exposed center post of
the hose firmly into the power washer's water outlet on
the right side of the machine, then twist the collar to
secure it. Confirm the hose is secure by trying to lightly
pull it away from the machine.
16
Attach a garden hose to built in garden hose
adapter. The water is now connected to your power
washer.
Note: Flush out garden hose before connecting to
garden hose adapter.
10
F
N
N F
15
K
M
*I
Insert extension lance (*I) into nozzle holder (H), and
press spray gun (K) with extension lance (*I) into spray
gun holster (M).
17
Insert foam cannon (P) into hose holder (A) by pressing
into the slot in the back nozzle.
You have now completed the assembly and are ready
to begin using your electric power washer. Read and
observe all safety instructions.
A
P
