Blue Clean AR 1850 Assembly, Care And Use Instructions

Electric pressure washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

1850 PSI
Electric Pressure Washer
95028-LM
95028_IM_ARBC_AR1850_EN_REV00_20181224.indd 1
ASSEMBLY, CARE AND
USE INSTRUCTIONS
Model AR 1850
READ CAREFULLY
IMPORTANT:
RETAIN THESE INSTRUCTIONS
AND
ATTACH RECEIPT TO MANUAL FOR FUTURE
REFERENCE.
WARNING:
This product can expose you to
chemicals including lead, DEHP, DINP, which is
known to the State of California to cause cancer
and or lead to birth defects. For more information
go to www.P65Warnings.ca.gov
Questions, problems, missing parts?
Before returning to your retailer, call (1-866-235-5112)
or email (info@arnorthamerica.com) our customer
service department. They are available from 8:00 a.m. -
5:00 p.m., CST, Monday - Friday. www.arblueclean.com
2018/12/25 下午3:58

Advertisement

Table of Contents
loading

Related Manuals for Blue Clean AR 1850

Summary of Contents for Blue Clean AR 1850

  • Page 1 1850 PSI Electric Pressure Washer ASSEMBLY, CARE AND USE INSTRUCTIONS Model AR 1850 READ CAREFULLY IMPORTANT: RETAIN THESE INSTRUCTIONS ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE. WARNING: This product can expose you to chemicals including lead, DEHP, DINP, which is known to the State of California to cause cancer and or lead to birth defects.

  • Page 2: Table Of Contents

    Troubleshooting ....................... 14 Limited Warranty ......................15 Replacement Parts List ....................16 PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS SPECIFICATIONS Max PSI Max GPM Frequency Weight (lbs.) Model (lbs/sq. in.) (Gal/per min) Cold Water Volts (Hz) Amps AR 1850 1850 ✔ 95028_IM_ARBC_AR1850_EN_REV00_20181224.indd 2 2018/12/25 下午3:58...

  • Page 3: Package Contents

    PACKAGE CONTENTS PACKAGE CONTENTS PACKAGE CONTENTS PW9091850 PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Power Washer Unit Garden Hose Adapter Spray Gun Holster High Pressure Foam Cannon Nozzle Cleaning Wire Spray Gun Spray Gun Trigger Lock Super Soft High Pressure Hose O-Ring Kit Nozzle Tray Screw...

  • Page 4: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION SAFETY INFORMATION Please read and understand this entire manual before 9. DO NOT use your power washer when you are under attempting to assemble and operate the product. the influence of alcohol or drugs. Use this power tool carefully and only when you are alert.
  • Page 5 35. NEVER use lances or other parts that are not to protect pumps. compatible for this specific AR Blue Clean unit. 36. NEVER use an extension power cord since it defeats 27. NEVER use hot water with your power washer. It will the effectiveness of the GFCI and increases the overheat and damage the high pressure pump.

  • Page 6: Assembly Instructions

    PREPARATION PREPARATION PREPARATION Before beginning assembly of product, make sure Tools Required for Assembly (not included): Phillips all parts are present. Compare parts with package screwdriver. contents list and hardware contents list. If any part is missing or damaged, DO NOT attempt to assemble the product.Please call customer service at 1-866-235- 5112.
  • Page 7 ASSEMBLY INSTRUCTIONS Super Soft High Pressure Hose Assembly Screw Super Soft high pressure hose (D) clockwise onto bottom front of power washer unit (A). Pull back collar and insert o-ring post into water outlet far enough so collar can thread onto outlet threads until hand tight. If it takes fewer than six turns you have not properly tightened the Super Soft high pressure hose fitting.
  • Page 8 PREPARATION ASSEMBLY INSTRUCTIONS Lock Unlock igh/Low Nozzle Lance and High Pressure Foam Cannon Installation While the spray gun (I) is in the locked position, insert Locking Spray Gun (Before Lance Installation) the high/low nozzle lance (F) or high pressure foam To lock the trigger of the spray gun (I), aim the gun cannon (H) into the end of the spray gun, by inserting away from you and push the lock button from right to...

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS OFF/0 OFF/0 ON/I ON/I • Turn the power switch to the “ON” (|) position. The unit will turn on for 1 - 2 seconds and shut off. This is a normal function of the auto start feature. Squeeze the spray gun trigger to begin pressure washing.
  • Page 10 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS IN position IN position High Pressure Setting Fan Spray Pencil Stream Attach Foam Canon (stored in rear of pressure washer) Using High/Low Nozzle into end of lance by pressing cannon into place.It will • The adjustable spray nozzle had has two (2) make a “click”...
  • Page 11 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Operation Tips • Note: Test the GFCI before each use: 1. Plug GFCI into power outlet. Indicator should turn green to show that cord has power. 2. Press test button, green indicator should turn off to verify that GFCI cut off power to the cord.

  • Page 12: Care And Maintenance

    OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Extending and Lowering Handle Using Power Cord • Extend the handle up by pressing the blue button in • Easily remove the power cord from side of unit by the cord hook and pull handle up until it locks in place. swiveling the bottom blue cord hook to the right or Note: If handle does not easily slide up, add some left until it faces up.

  • Page 13: Pump Saver

    To prevent staining, protect the surface under stored in ALL climates. It also assists with protection from the power washer from any excess fluid. Wear eye internal corrosion. The Blue Clean part # is: PW64511 protection when using this product. (16oz. bottle). Order online at www.arblueclean.com 95028_IM_ARBC_AR1850_EN_REV00_20181224.indd 13...

  • Page 14: Troubleshooting

    PUMP SAVER CARE AND MAINTENANCE Turn unit off and disconnect the gun before adding 5) Turn power off when pump saver exits the machine’s pump protector. Unscrew threaded top from bottle to water outlet. remove seal and reattach threaded top to bottle. Remove black cap from bottle.

  • Page 15: Limited Warranty

    CARE AND MAINTENANCE TROUBLESHOOTING PROBLEM CORRECTIVE ACTION Why is water leaking 1. Make sure there is an o-ring at the end of the metal tip of the high pressure hose. If where the high no o-ring is present, the connection between the hose and spray gun will leak. O-Ring pressure hose Replacement Kit (K) is included with purchase.

  • Page 16: Replacement Parts List

    CARE AND MAINTENANCE TROUBLESHOOTING LIMITED WARRANTY company will repair or replace the unit. We will send unit back to customer at no charge. Please note: Power washers sent to the company without an RMA Number will NOT be accepted and will be shipped back at the expense of the sender.
