- Page 1 Kaba EF780 Please read these instructions carefully before you use the product. Functions and design of this product are subject to change without prior notice due to product improvement.
- Page 2 Disassembly, rework and reverse engineering are prohibited without a written approval of KABA except for normal ● installation of the product.
-
Page 3: Table Of Contents
Table of Contents Components 3-15.Remote Control Deletion 3-16.Sound Volume Setting 3-17.Double Identification Mode Registration Name of Parts 3-18.Double Identification Mode Deletion 2-1.Outside Lock (Front Body) 3-19.Open a Door From Outside 2-2.Inside Lock (Main Body) 3-20. Open a Door From Inside 3-21. - Page 4 Safety Regulations To ensure your own safety and prevent any damage or accident caused by the inappropriate use of the product, please read carefully before you start to use the product. Children should be under the guidance of an adult to ensure the safety use of the product. Keep this manual in a safe place for future reference.
- Page 5 Installation Do not wash the product with Do not disassemble, reassemble or Do not press a button too water as electronic circuit may repair the product by yourselves. hard or use a foreign object break down in contact with water. This may cause the damage or to hit it.
- Page 6 N. B for Installation Do not clean the product Do not wear gloves Keep the keypad clean Use a new alkaline battery with direct contact with to touch the keypad and away from foreign (AA size). Otherwise, it water or wipe it with as the system cannot substance at all times may cause the malfunction...
-
Page 7: Components
Components Basic Components (Kaba EF780) screw mortise strike plate strike box user manual (5 nos) (2 nos) outside part inside part spindle guide screw (3 nos) battery (AA) button cell battery (built-in) (front body) (main body) (4 nos) remote control... -
Page 8: Name Of Parts
Name of Parts Outside Lock (Front Body) Emergency Power Supply Socket Keypad Fingerprint Reader When the battery is fully discharged, a 9V For you to enter a battery can be used to supply power to operate number such as a PIN Indentifies a fingerprint the product temporarily as an emergency code, user ID and menu... -
Page 9: 2-2.Inside Lock (Main Body)
2-2 Inside Lock (Main Body) Battery Cover Management Button [M] Reset an admin PIN code and factory default. Privacy Mode Light Clear Button [E] Displays the status of the privacy mode. Delete all information (except admin Privacy Mode Switch(under the status of door locked) PIN code) and reset factory default. -
Page 10: How To Use
How to Use 3-1 Factory Reset Press [M] and [E] button Input 8-digit admin PIN Open the battery cover. Remove one piece of battery and put back the battery code and press “#” button simultaneously. Voice guide: “1 Chinese 2 English” Voice guide: “Please Input PIN Code”... -
Page 11: 3-2.Reset Admin Pin Code
3-2 Reset Admin PIN Code 3-3 Delete All User Information Input a new 8-digit PIN Open the battery cover and Input 8-digit admin PIN Open the battery cover and code and press “#” button press [M] for 10 seconds code and press “#” button press [M] for 10 seconds Voice guide: Voice guide:... -
Page 12: 3-4.How To Enter The Menu
3-4 How to Enter the Menu Enter the menu by admin Enter the menu by admin Example of placing fingerprints on the fingerprint sensor fingerprint. PIN code Place admin fingerprint on Input admin PIN code and “Good Example” “Poor Example” the fingerprint reader press “#”... -
Page 13: 3-5.Instruction Overview
3-5 Instruction Overview Wireless Communication Setting Fingerprint management (only aplicable to the model with wireless communication) Fingerprint Fingerprint General fingerprint Place the fingerprint Input user ID registration registration on the card reader management Wireless Turn on wireless Communication ... -
Page 14: 3-6.Fingerprint Registration
3-6 Fingerprint Registration Enter the menu and press 1 Place a fingerprint on the Press 1 and # on the Choose the user category and # button on the keypad fingerprint reader keypad Voice guide Voice guide Voice guide Voice guide “Operation succeeded”... -
Page 15: 3-7.Delete An Individual Fingerprint
3-7 Delete an Individual Fingerprint 3-8 Delete All Fingerprints Enter the menu and press 1 Input the user ID you wish Enter the menu and press 1 Choose the user category and # button on the keypad to delete and press # button and # button on the keypad Voice guide Voice guide... -
Page 16: 3-9.Pin Code Registration
3-9 PIN Code Registration Input 8-digit PIN code Enter the menu and press 3 Press 1 and # Choose the user category twice and press # button and # button on the keypad on the keypad to confirm respectively Voice guide Voice guide Voice guide Voice guide... -
Page 17: 3-10.Delete An Individual Pin Code
3-10 Delete an Individual PIN Code 3-11 Delete All PIN Codes Enter the menu and press 3 Input the user ID you wish Enter the menu and press 3 Choose the user category and # button on the keypad to delete and press # button and # button on the keypad Voice guide Voice guide... -
Page 18: 3-12.Turn On Wireless Communication
3-12 Turn On Wireless Communication 3-13 Turn Off Wireless Communication Enter the menu and press 4 Press 1 and # on Enter the menu and press 4 Press 2 and # on and # button on the keypad the keypad and # button on the keypad the keypad Voice guide... -
Page 19: 3-14.Remote Control Registration
3-14 Remote Control Registration Enter the menu and press 4 and # Press two buttons on remote control Press 3 and # on the keypad button on the keypad simultaneously Voice guide Voice guide Voice guide “1 Turn on wireless communication, “Please input user ID”... -
Page 20: 3-15.Remote Control Deletion
3-15 Remote Control Deletion 3-16 Sound Volume Setting Choose the sound volume Enter the menu and press 4 Input the user ID and Enter the menu and press 5 category and press # and # button on the keypad and # button on the keypad press # button button to confirm Voice guide... -
Page 21: 3-17.Double Identification Mode Registration
3-17 Double Identification Mode Registration Enter the menu and press 5 Press 5 and # on Press 1 and # on Input 8-digit PIN code and # button on the keypad the keypad the keypad and press # button Voice guide Voice guide Voice guide Voice guide... -
Page 22: 3-18.Double Identification Mode Deletion
3-18 Double Identification Mode Deletion Enter the menu and press 5 Press 5 and # on Press 3 and # on the Input double identification and # button on the keypad the keypad keypad user ID and press # button Voice guide Voice guide Voice guide... -
Page 23: 3-19.Open A Door From Outside
3-19 Open a Door From Outside Open a door with a fingerprint Open a door with a PIN code Open a door with a remote control 1. Place a registered 1.Touch the 1.Press [ ] button on the registered remote fingerprint on the keypad with your control... - Page 24 Open a door with PIN code and Open a door with fingerprint and Open a door with a mechanical key fingerprint double identification mode fingerprint double identification mode 1. Touch the keypad 1.Place a registered fingerprint on the 1.Slide the handle cover with your palm fingerprint reader 2.Insert the mechanical key and rotate 90 degree.
-
Page 25: Open A Door From Inside
3-20 Open a Door From Inside 3-21 Lock a Door From Inside A door can be opened when you turn [LOCK] Mode [PASSAGE/Open] Mode the door handle downward A door is locked automatically when the door In [PASSAGE/Open] mode, door will not be is closed. -
Page 26: Pin Code Registration
3-22 Language Setting 3-23 Passage/Open Mode Setting Deactivate Passage/Open Activate Passage/Open Mode Enter the menu and press 5 Press 3 and # on Mode and # button on the keypad the keypad In passage mode, 0 button will keep flashing Voice guide Voice guide “1 Chinese, 2 English”... -
Page 27: 3-25 Trespassing/Damage Alarm
3-25 Trespassing/Damage alarm 3-26 SOS Alarm When the door is securely locked, an alarm will be activated if an outsider tries to break into the premises by forcibly opening a door or damaging the door lock. Trespassing alarm Damage alarm SOS Alarm An alarm will be activated if an An alarm will be activated if an... -
Page 28: 3-27 Keypad Lockout Alarm
3-27 Keypad Lockout Alarm 3-28 3-29 Security Linkage Alarm Low Battery Alarm (optional) If a wrong PIN code or fingerprint is The lock can be connected with the Please replace the battery when the low entered for 3 times consecutively, this security housekeeper by wireless. -
Page 29: Trouble Shooting
Trouble Shooting 4-1 How to Replace a Battery When the product is being used and the battery needs to be replaced, the battery change LED light on the lower left will illuminate if the keypad is touched. Voice guide Low battery, please replace batteries Open the cover of the main body Replace the battery Unfasten the screw on the battery cover... -
Page 30: 4-2.Solutions To Malfunction Of The Product
4-2 Solutions to Malfunction of the Product How to use a 9V battery If the product stops working due to the battery discharge, insert a 9V square battery and use a PIN code or a card key to open the door. Purchase a 9V battery in the nearest convenience store or any electronic shops. -
Page 31: 4-3.Trouble Shooting
4-3 Trouble Shooting If the product is not working properly, please ensure that you have read the following table carefully before you go to contact After Sales Service. If a problem persists, Please contact After Sales Service for further assistance. Classification Problem Check Points... - Page 32 Classification Problem Check Points Check if the lock is set as Mute No sound A door cannot be unlocked with a Check if the privacy mode is set from inside, a door cannot be opened using a PIN code or a PIN code or a fingerprint from fingerprint from outside outside and the lock voice guide...
-
Page 33: Product Specification
Product Specification Standard Remark Part Front Body 26.9(D) x 74(W) x 285(H) Zincdiecasting Main Body 27.9(D) x 74(W) x 285(H) Zincdiecasting Rated Voltage DC 6V Canuse1yearonabasisofusing10timesperday(can use10-monthdurabilityifitisamodelwithremotecontroller) Working Temperature ℃ -10 ~ 55 Battery 1.5 V AA alkaline batteries(4 nos) FSK, 433.92 MHz Remote Controller Only applicable to models with remote controller... - Page 34 Memo...
