Function Setting Items - Zoom RhythmTrak RT-223 Operation Manual

Changing Various Settings of the RT-223
new setting becomes effective immediately.
To return to the previous setting, perform
the setting procedure again.
4.
Press the [FUNCTION] key once
more, or press the [EXIT] key.
The function setting mode is terminated.
HINT
The [FUNCTION] key is also used for demo
→
song playback (
39), and other functions.

Function setting items

This section explains the various items that can be
set and gives information on the setting range.
■ Setting bass program reference
pitch (BASS KEY)
Setting range: C - B
This sets the pitch assigned to pad 0 in the range
from C to B. The note set here also expresses the
root of the pattern.
When you use the VALUE [+]/[-] keys to change
the pitch of pad 0, the pitch of pads 1 - 9, [+], [x],
and [()] also is shifted accordingly.
A sharp pitch (#) is expressed as "
stands for #).
HINT
This setting is stored for each pattern
individually.
■ Setting the drum track/bass
track level (MIX)
Setting range: 0 - 15
Sets the volume for each track in a pattern over a
range of 0 - 15.
After selecting this item, use the [DRUM] or
[BASS] key to select the track and then use the
VALUE [+]/[-] keys to make the setting.
64
→
p. 8), FAST input ( p.
" (where o
HINT
This setting is stored for each pattern
individually.
■ Tuning a bass program (BASS
TUNE)
Setting range: 435 - 445 (Default: 440)
Allows tuning the bass program in the range of A
= 435 Hz to A = 445 Hz.
■ Setting the time signature of a
pattern (TIME SIG)
Setting range: 1, 2, 3, 4, 5, 6, 7, 8
Set the time signature for the pattern to 1 - 8 (1/4 -
8/4 beat).
The time signature of an already recorded pattern
(indicated by "*" on the display) is not possible.
HINT
This setting is stored for each pattern
individually.
■ Setting the pre-count (PRE COUNT)
Setting range: oFF, 1 - 8, SP (Default: 4)
The pre-count (number of metronome ticks before
the start of pattern real-time recording) can be
turned on and off, and the number of measures
etc. can be set. This setting applies to all patterns.
The settings have the following meaning.
• oFF
Pre-count is off.
• 1 - 8
Real-time recording starts after the respective
number of measures has been counted.
• SP
Real-time recording starts after the following
special pre-count was heard.
ZOOM RT-223
