5.
Use the cursor left/right keys to
select the type of event to enter.
Available event types are shown in the following
table.
Event type
Description
PTN
Pattern number
TIMSIG
Beat
ROOT
Bass track root
Tempo
TEMPO
DR VOL
Drum track volume
BS VOL
Bass track volume
DR KIT
Drum kit
BS PRG
Bass program
If you select an event for which information has
already been input at the current position, the
event name and setting value are shown on the
display. (By pressing the VALUE [+]/[-] keys in
this condition, you can change the setting.)
DR VOL
Event name
Event setting value
If you select an event for which no information
has been input at the current position, the
indication "←xxx" (where xxx is the event name)
i s s h o w n . T h i s m e a n s t h a t t h e p r e c e d i n g
information for the same event type remains
valid. The following illustration shows an
example for the display when the TEMPO event
is selected.
ZOOM RT-223
Setting range
000 – 511
1 – 8
(1/4 – 8/4)
E – D#
40 – 250
0 – 15
0 – 15
0 – 126
0 – 11
15
Creating Songs (Song Mode)
TEMPO
Event name
HINT
• If you enter tempo information at the
beginning of a song, the song will always
play at that tempo, regardless of current
tempo settings.
• If the root set for a pattern with BASS KEY
(
p. 64) and the root set for the song are
different, the bass phrase is transposed to
match the root entered for the song. For
example, if the pattern root is set to C for
the phrase "G - A - B", and the song root is
set to D, the resulting phrase will be "A -
B- C#".
6.
Use the VALUE [+]/[-] keys to enter
the setting value.
When you specify the setting value with the
VALUE [+]/[-] keys, the indication "←xxx"
(where xxx is the event name) changes to the
event name only. This indicates that new event
information has been input at the current position.
TEMPO
Event name
7.
When event information for the
current position has been input,
press the [EXIT] key to return to the
song step input screen.
If required, repeat steps 3 - 7 for other events.
---
125
Entered value
43
