Shipping And Handling; Packing; Inspection; Handling - S&C TripSaver II Pairing Manual

Shipping and Handling

Packing

A complete TripSaver II Cutout-Mounted Recloser for a
new installation consists of two shipping containers. They
include the following:
• A single-pole TripSaver II Cutout-Mounted Recloser
• A mounting and miscellaneous mounting hardware for
securing the TripSaver II recloser to the pole
A complete TripSaver II Communications via Gateway
system for a new installation consists of two shipping
containers. They include the following:
• The communications gateway (including radio, if speci-
fied "factory-furnished" at time of order), an optional
battery if specified, and mounting hardware for securing
the box to the pole
• An ac power cable

Inspection

Examine the shipment for external evidence of damage as
soon after receipt as possible, preferably before removal
from the carrier's conveyance. Check the bill of lading to
make sure the listed shipping containers are present:
If there is visible loss and/or damage:
1. Notify the delivering carrier immediately.
2. Ask for a carrier inspection.
3. Note the condition of shipment on all copies of the
delivery receipt.
4. File a claim with the carrier.
If concealed damage is discovered:
1. Notify the delivering carrier within 15 days of receipt of
shipment.
2. Ask for a carrier inspection.
3. File a claim with the carrier.
Also, notify S&C Electric Company in all instances of
loss and/or damage.
6 S&C Instruction Sheet 461-521

Handling

NOTICE
DO NOT drop a TripSaver II recloser or subject any
of its parts to undue stress during installation . Only
remove a TripSaver II recloser from the carton when
you are ready for installation .

Storage

TripSaver II Cutout-Mounted Reclosers and TripSaver II
Communications Gateways are shipped on pallets banded
with plastic wrap. This packaging is designed to protect
the TripSaver II reclosers and Communications Gateways
from freight damage. This packaging is not suitable for
outdoor storage as it can trap water and moisture that
may damage the equipment. After receipt, TripSaver II
reclosers and TripSaver II Communications Gateways
should be stored indoors in their shipping packaging.
Storing TripSaver II reclosers or Communications
Gateways outdoors in the shipping packaging will void
the warranty.

Returning

If for any reason a TripSaver II recloser or TripSaver II
Communications Gateway is to be returned, place it in
the original shipping carton to prevent damage during
shipping. If you need additional shipping cartons, contact
your nearest S&C Sales Office, S&C Authorized Distributer,
or S&C Headquarters.

Equipment Required

To perform the procedures detailed in this instruction
sheet, you will need:
• A TripSaver II Cutout-Mounted Recloser with the
Extended Open Interval ("-O") option
• A TripSaver II Communications Gateway with battery
backup
• The TripSaver II Service Center Configuration Software
installed on a PC
• The TripSaver II Service Center Configuration Kit
including the power module, ac cord, and USB trans-
ceiver
• The S&C Magnet Tool (or equivalent strong magnet)
• An Ethernet cable
