Industrial USB 2.0 Hub
with 15KV ESD Protection
Quick Installation Guide
Introduction
The Industrial USB 2.0 Hub with 15KV ESD Protection
easily adds multiple industrial standard USB 2.0 ports to
your system.
Features and Benefits
•
Supports high-speed (480Mb/s), full-speed (12Mb/
s), and low-speed (1.5Mb/s) data transfer modes
•
Supports High-speed and Full-speed Packet
Protocol Sequencer for Endpoint 0/1
•
Supports redundant 9 to 24 VDC power inputs
•
Built in 15KVDC ESD USB interface protection
•
Power input surge protection (600W) for each port
•
Independent over-current protection
•
External power supply (9V to 24V DC) to supply
enough power for power hungry devices
•
Metal housing with DIN-Rail and wall mounting
built-in
System Requirements
•
Desktop or notebook with an available USB port
•
Windows
/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-
/64-bit) / Server 2008 R2 / 2000
04-0865A
8 (32-/64-bit) / 7 (32-/64-bit) / Vista (32-
®
1
Advertisement
Table of Contents
Related Manuals for SIIG ID-US0211-S1
Summary of Contents for SIIG ID-US0211-S1
- Page 1 Industrial USB 2.0 Hub with 15KV ESD Protection Quick Installation Guide Introduction The Industrial USB 2.0 Hub with 15KV ESD Protection easily adds multiple industrial standard USB 2.0 ports to your system. Features and Benefits • Supports high-speed (480Mb/s), full-speed (12Mb/ s), and low-speed (1.5Mb/s) data transfer modes •...
-
Page 2: Package Contents
Package Contents • Industrial USB 2.0 Hub with 15KV ESD Protection • USB Type A to B cable • DIN-Rail & wall mount kit • Terminal block • Quick installation guide Layout Industrial 4-Port USB Hub 3 pin terminal Downstream ports block (USB Type A) DC power... -
Page 3: Powering The Hub
Powering the Hub Use an external power adapter (not included), with selectable 9V to 24V DC output, and connect it to the hub's DC Power Jack or 3-Pin Terminal Block. Note: The hub requires an external power adapter (not included) to work properly. DC Power Jack Plug the power adapter into a reliable power source then connect it to the hub's DC Power Jack. -
Page 4: Pin Assignment
Pin Assignment 3-Pin Terminal Block Figure 5 USB Type B Upstream Port Figure 6... -
Page 5: Hardware Installation
Hardware Installation Mount your hub on the wall or DIN-Rail, if needed. DIN-Rail Mounting Use the included screws to install the DIN-Rail kit to the hub. DIN-Rail kit Figure 7 Insert the top of the DIN-Rail clip onto the DIN-Rail track, then gently push the bottom of the hub to secure it to the DIN-Rail track. -
Page 6: Wall Mount Plate Mounting
Wall Mount Plate Mounting Use the provided Wall Mount Plate to mount the hub to the wall. See Figure 9. Wall Mount Plate Wall Wall Wall Mount Plate Figure 9... -
Page 7: Technical Support And Warranty
(3) years from the date of purchase of the product. SIIG will, at our discretion, repair or replace (with an identical product or product having similar features and functionality) the product if defective in materials or workmanship. - Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 Industrial USB 2.0 Hub with 15KV ESD Protection is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
