General machine data

Number MD Name
Unit Name, Miscellaneous
HW / function Standard value
10074 PLC_IPO_TIME_RATIO
– PLC task factor for main run
2
10240 SCALING_SYSTEM_IS_METRIC
– Basic system metric
_always 1
11100 AUXFU_MAXNUM_GROUP_ASSIGN
– Number of auxiliary functions distr. amongst aux. fct.
groups
_always 1
11200 INIT_MD
HEX Standard machine data loaded on next Power On
_always 0x0F
11210 UPLOAD_MD_CHANGE_ONLY
HEX Saving only of modified MD (value=0: complete= no
difference)
- 0x0F
11310 HANDWH_REVERSE
– Threshold for direction change handwheel
_always 2
11320 HANDWH_IMP_PER_LATCH
– Handwheel pulses per detent position (handwheel
number): 0...1
_always 1., 1.
11346 HANDWH_TRUE_DISTANCE
– Handwheel
_always 0
14510 USER_DATA_INT [n]
kB User data (INT) 0 ... 31
_always –
14512 USER_DATA_HEX [n]
kB User data (Hex) 0 ... 31
– 0
6-4
Minimum value
1
***
1
–
-
0.0
–
0
0
0
Activated
Maximum value D type
POWER ON
50 DWORD 2/7
POWER ON
*** BOOLEAN 2/7
POWER ON
50 BYTE
POWER ON
– BYTE
RESTART
- BYTE
POWER ON
plus BYTE
POWER ON
– DOUBLE 2/7
POWER ON
3 BYTE
POWER ON
– DWORD 2/7
POWER ON
0xFF BYTE
