Installing the Control System

2.1

Installing and Dismantling the SINUMERIK 802C base line

!
Approach
Dismantling the control system
SINUMERIK 802C base line
Start-Up
Warning
Do not install when the equipment is under power!
The modules contain electrostatically sensitive devices.
It must be ensured that persons without ESD protection never touch printed
circuit boards or components when handling operator and machine control
panels.
Due to the compactness, it is very convenient to install and dismantle the
control system.
1. Fix the system in the machine control station.
2. Screw the system in place with 8 M4 x 16 assembled screws. The
maximum allowed torque for the screws is 1.5 Nm.
Notice
Prior to installation, the machine control panel can be provided with an
emergency stop button. If it is not required, the opening must be covered with
the supplied self-adhesive cover.
The control system is dismantled as described above in the reverse order.
Warning
Do not dismantle when the equipment is under power!
2
2-1
