VST Installation Procedure for
Phase II EVR Vacuum Assist
Safety Breakaway Devices
Part Number Series:
VST-HEVR-SBK;
VST-ISVR-SBK
13. After the two breakaway halves are properly snapped together, remove the
VST Breakaway Assembly Tool (press the button on the tool to allow it to
release), and give the reassembled breakaway a strong pull to verify that it
is properly connected.
14. Perform Section 1.4 – Procedure for Operator Reconnection of Breakaway
and Testing Fueling Point after a Drive-Off in the Assist Systems Scheduled

Maintenance.

METHOD 2: Without the use of the VST Breakaway Assembly Tool.
1. Follow INSTALLATION PREPARATION steps 1 - 5.
2. Disconnect hoses from the safety breakaway halves.
3. Inspect both safety breakaway halves for damage that may have occurred
during separation. Include looking for external damage to the product,
damaged threads, damaged O-rings, missing O-rings, proper placement of
O-rings, etc. If damage is detected, replace with new product.
4. Prior to reassembling, be sure the mating parts are undamaged and clean.
Figure 3.
Anti-Rotation Studs and Slots
2 Anti-Rotation Studs and Slots
CARB Approved IOM 6 – EVR Vacuum Assist Breakaways VR-201 and VR-202
5. Lightly lubricate ALL O-rings on mating connections with petroleum jelly or
other suitable lubricant.
6. Carefully align the 2 breakaway halves.
a. Align the anti-rotation studs inside the breakaway half on the curb hose
with the slots on the other half of the breakaway -inside the breakaway
half on the whip hose. See Figure 3.
7. The two aligned breakaway halves need to be assembled concentrically
(properly aligned) until they snap into place.
a. Listen for a "click" to indicate that the two halves have been properly
reattached.
b. If the two breakaway halves become cocked (misaligned) or otherwise
do not snap together easily, pull them apart and start over.
8. After the two breakaway halves are properly snapped together, give
the reassembled breakaway a strong pull to verify that it is properly
connected.
9. Perform Section 1.4 – Procedure for Operator Reconnection of Breakaway
and Testing Fueling Point after a Drive-Off in the Assist Systems Scheduled
Maintenance.
MAINTENANCE
Inspect breakaways regularly for damage, loose connections or leaks. Replace
as necessary. Subject to customer abuse, breakaways should be replaced when
damaged.
The breakaway is designed and constructed to give lasting service if properly
handled and maintained. If for any reason it should need attention, contact your
VST distributor for proper disposition.
NOTE:
Due to abuse, misuse, changing gasoline formulas, variation in maintenance
practices, environmental conditions and/or conditions beyond the manufacture's
control, dispensing equipment may need replacement before five (5) years.
Inspections and proper maintenance procedures should be followed by the
station manager to determine if replacement is required before five (5) years.
WARNING
Unauthorized rebuilding or modifying of breakaways voids ALL approvals and
warranties.
VST products must be used in compliance with applicable federal, state and
local laws and regulations.
