Summary of Contents for Watson-Marlow BREDEL 701 Series
-
Page 1: Table Of Contents
Watson-Marlow Bredel E-Manuals Page 1 of 25 WATSON-MARLOW BREDEL E-MANUALS PB0230GB02 Watson-Marlow 701 baseplate pumps Contents 1. Declaration of conformity 16. 701RB, 701RBX, 701RBG, 701RBE, 701RBEX 2. Declaration of incorporation Pump installation 3. Warranty 17. Tube loading 4. Information for returning pumps 18. - Page 2 Watson-Marlow Bredel E-Manuals Page 2 of 25 file://M:\staging\pdfs-global\m-701baseplate-gb-02.htm 14/12/2009...
-
Page 3: Declaration Of Conformity
Watson-Marlow Bredel E-Manuals Page 3 of 25 1 Declaration of conformity When this pump unit is used as a stand alone pump it complies with: Machinery Directive 2006/42/EC, EMC Directive 2004/108/EC. file://M:\staging\pdfs-global\m-701baseplate-gb-02.htm 14/12/2009... -
Page 4: Declaration Of Incorporation
Machinery Directive 2006/42/EC. Responsible person: Christopher Gadsden, Managing Director, Watson-Marlow Limited, Falmouth, Cornwall TR11 4RU, England. Telephone +44 (0) 1326 370370 Fax +44 (0) 1326 376009. -
Page 5: Information For Returning Pumps
damage or electrical surge are excluded. Warranties purporting to be on behalf of Watson-Marlow Limited made by any person, including representatives of Watson-Marlow Limited, its subsidiaries, or its distributors, which do not accord with the terms of this warranty shall not be binding upon Watson- Marlow Limited unless expressly approved in writing by a Director or Manager of Watson- Marlow Limited. -
Page 6: Safety
Watson-Marlow Bredel E-Manuals Page 6 of 25 5 Safety In the interests of safety, this pump and the tubing selected should only be used by competent, suitably trained personnel after they have read and understood this manual, and considered any hazard involved. Any person who is involved in the installation or maintenance of this equipment should be fully competent to carry out the work. -
Page 7: Recommended Operating Procedures
Do keep the pumphead rollers and track clean. If unsure of an installation please contact your local Watson-Marlow Technical Support Office for further assistance. The self-priming nature of peristaltic pumps means valves are not required. Any valves fitted must cause no restriction to flow in the pumping circuit. -
Page 8: Installation
Watson-Marlow Bredel E-Manuals Page 8 of 25 7 Installation Pump Site the pump on a flat, horizontal, vibration-proof surface allowing a free flow of air around it. Ensure there is 1m of relatively straight flexible tubing before the pumphead inlet and after the pumphead outlets. -
Page 9: Troubleshooting
Watson-Marlow Bredel E-Manuals Page 9 of 25 Do not under any circumstances wire switches directly across any of the phases of a 3-phase supply. If in doubt disconnect the pump immediately! Do not connect ancillary switches to the terminal box of a flameproof motor unless the switch has a suitable Ex rating for the zone area in which it is to be mounted. -
Page 10: 1Pb Air Motors
Watson-Marlow Bredel E-Manuals Page 10 of 25 Replacing the V-belt Unscrew the socket head screws and remove the cover with the entire speed control mechanism. Remove the V-belt. Wrap the new V-belt around the open adjustable pulley and let it slip over the spring ... -
Page 11: 1Pb Air Motors: Troubleshooting
Watson-Marlow Bredel E-Manuals Page 11 of 25 Lubrication Use a detergent SAE#10 automotive engine oil. Lubrication is necessary for all moving parts and rust prevention. We recommend that an automatic air lubricator be installed in the air line just ahead of the motor. -
Page 12: Pump Specification
Watson-Marlow Bredel E-Manuals Page 12 of 25 13 Pump specification Control range See pump specification label Voltage/frequency See pump specification label Power consumption See pump specification label Operating temperature range 5°C to 40°C Storage temperature range -40°C to 70°C Noise <85dBA at 1m... -
Page 13: 1Rb, 701Rbx, 701Rbg, 701Rbe, 701Rbex
Do keep the pumphead rollers and track clean. If unsure of an installation please contact your local Watson-Marlow Technical Support Office for further assistance. All performance figures in this operating instruction relate to peak pipeline pressures. Peak pressure is not always accurately shown by oil-filled analogue pressure gauges as damping of the gauge needle occurs. -
Page 14: Tube Loading
17 Tube loading 701 baseplate pumps can be operated with a 701RB continuous tubing pumphead or with a 701RBE pumphead fitted with Watson-Marlow LoadSure tube elements. For both pumphead types, extension "X" pumphead options are available. 701R, 701RB and 701RBX continuous tube loading Loosen the track compression spring knobs using a 10mm A/F spanner, turning them ... - Page 15 Watson-Marlow Bredel E-Manuals Page 15 of 25 Fit the delivery clamp loosely to allow any excess tubing to work its way through the pumphead. (See Re-tensioning the tubing, below) Position the track over the pumphead cradle and locate the track securing bolt. Tighten ...
- Page 16 Watson-Marlow Bredel E-Manuals Page 16 of 25 701RBE and 701RBEX LoadSure tube element loading 700 series LoadSure tube elements: remove the chance of premature tube failure caused by incorrect tube loading; avoid over-clamping of tubing; remove the need to re-tension the tubing;...
-
Page 17: Fitting An Extension Pumphead
Watson-Marlow Bredel E-Manuals Page 17 of 25 Position the left-hand end of the track so that the track-securing bolt can be inserted. Tighten the track-securing bolt with the 6mm Allen key provided. Tighten both the track-compression spring knobs to a torque of 3Nm (2.2 lb-ft) using a ... -
Page 18: Pumphead Spares: Continuous Tubing
Watson-Marlow Bredel E-Manuals Page 18 of 25 19 Pumphead spares: continuous tubing Models 701RB, 701RBX, 701RBG 1 MRA0027A Pivot pin assembly 1 MRA0034A Pivot pin assembly ~701RX 2 MRA0021A Rotor assembly 2 MRA0036A Rotor assembly ~ 701RX 3 701RB, 701RBX:... -
Page 19: Pumphead Spares: Tubing Elements
Watson-Marlow Bredel E-Manuals Page 19 of 25 20 Pumphead spares: tubing elements Models 701RBE, 701RBEX 1 MRA0027A Pivot pin assembly 1 MRA0034A Pivot pin assembly ~701RX 2 MRA0021A Rotor assembly 2 MRA0036A Rotor assembly ~ 701RX 3 MRA0104A Knob assembly ~ 4.8mm wall... -
Page 20: Flow Rates
Watson-Marlow Bredel E-Manuals Page 20 of 25 22 Flow rates Flow rates were obtained using silicone tubing with the pumphead rotating clockwise, pumping water at 20°C with zero suction and delivery pressures. For critical applications determine flow rates under operating conditions. -
Page 21: 1Rb, 701Rbx, 701Rbg, 701Rbe, 701Rbex
Watson-Marlow Bredel E-Manuals Page 21 of 25 23 701RB, 701RBX, 701RBG, 701RBE, 701RBEX product codes Marprene Platinum inch Marprene Bioprene LoadSure silicone 902.0096.048 903.0096.048 913.A096.048 12.7 902.0127.048 902.0127.PPC 903.0127.048 913.A127.048 15.9 902.0159.048 902.0159.PPC 903.0159.048 913.A159.048 19.0 902.0190.048 902.0190.PPC 903.0190.048 913.A190.048 25.4... -
Page 22: Flow, Pressure And Suction
Watson-Marlow Bredel E-Manuals Page 22 of 25 24 Flow, pressure and suction 25 Maximum peak working pressure ratings 701RB 701RBX 701RBG 701RBE 701RBEX 2bar 2bar 4bar 2bar 2bar file://M:\staging\pdfs-global\m-701baseplate-gb-02.htm 14/12/2009... -
Page 23: Outline Dimensions
Watson-Marlow Bredel E-Manuals Page 23 of 25 26 Outline dimensions file://M:\staging\pdfs-global\m-701baseplate-gb-02.htm 14/12/2009... -
Page 24: Trademarks And Disclaimer
Sta-Pure is a trademark of W.L.Gore & Associates. Disclaimer The information contained in this document is believed to be correct but Watson-Marlow Limited accepts no liability for any errors it contains, and reserves the right to alter specifications without notice. -
Page 25: Decontamination Certificate
Hazardous to Health Regulations, you are required to declare the substances which have been in contact with product(s) you return to Watson-Marlow or its subsidiaries or distributors. Failure to do so will cause delays. Please ensure that you fax us this form and receive an RGA (Returned Goods Authorisation) before you despatch the product(s).
