DataTrak Controls and Indicators

Run Mode Key
AE Display
BCS Batch Counter Suppression (Enables batch counter sup-
pression mode. While in BCS mode, batch counting is
disabled and the LED will flash.)
BT Batch Totalizer (manually resettable to zero (0)). Counts
revolutions of the motor/agitator.
CF Speed (rpm)
GT Grand Totalizer (not manually resettable). Counts revolu-
tions of the motor/agitator. Resets automatically to zero
(0) after reaching 100 million revolutions. Note: Grand
Totalizer accuracy is limited to speeds below 400 rpm.
LED
F . 1. DataTrak Controls and Indicators
IG
3A7634A
LED LED (flashes during over-speed alert and in Batch
Counter Suppression mode)
RK Reset Key (Press and hold for 3 seconds to clear and
reset the Batch Totalizer).
Setup Mode Key
AA Over-speed setting, rpm (user settable; 000 = OFF). To
set over-speed, hold the BCS button for five seconds.
Use the RK button to set values, and the BCS button to
advance to the next unit and to exit setup mode.
AE Display

Run Mode

AE
0 0 0 0
RK
CF
AE

Setup Mode

0
RK
AA
DataTrak Controls and Indicators
GT
0 0 0 0
0 0 0 0 0
0
ti8622b
BT BCS
ti8623b
BCS
