Accessory
DataTrak
For monitoring speed and totalizing revolutions of radial piston motor-driven agitators. For
professional use only.
Model 25P394
®
Agitator DataTrak
Kit; includes DataTrak Module 24B563, reprogrammed for use with agitators.
Important Safety Instructions
Read all warnings and instructions in this
manual and in your agitator and agitator
rebuild kit manuals before using the
equipment. Save all instructions.
®
Kit
3A7634A
EN
Advertisement
Table of Contents
Related Manuals for Graco DataTrak
Summary of Contents for Graco DataTrak
- Page 1 Model 25P394 ® Agitator DataTrak Kit; includes DataTrak Module 24B563, reprogrammed for use with agitators. Important Safety Instructions Read all warnings and instructions in this manual and in your agitator and agitator rebuild kit manuals before using the...
-
Page 2: Table Of Contents
Contents DataTrak Operation......5 Related Manuals ......2 Setup Mode . -
Page 3: Setup Mode
(0) after reaching 100 million revolutions. Note: Grand Totalizer accuracy is limited to speeds below 400 rpm. Run Mode 0 0 0 0 0 0 0 0 0 0 0 0 0 ti8622b Setup Mode ti8623b . 1. DataTrak Controls and Indicators 3A7634A... -
Page 4: Datatrak Installation
DataTrak Installation DataTrak Installation Installing the Bracket on the Motor NOTE: The bracket can be mounted on either side. WARNING NOTE: A temporary bracket (6) can be used for taking a quick speed measurement. (See Parts, on page 7.) PRESSURIZED FLUID HAZARD... - Page 5 NOTE: The display (AE) may turn off if a high-level 3. Press to clear the diagnostic code and reset the static discharge is applied to the DataTrak. Press any key to wake up the display. over-speed display. NOTE: To disable over-speed monitoring, go to setup mode and set over-speed value to 0 (zero).
- Page 6 To reduce the risk of fire and explosion, the battery must be replaced in a non-hazardous location. Use only an approved replacement battery (see Table 2). Use of an unapproved battery will void Graco’s warranty and Intertek and Ex approvals. Table 2. Approved Batteries ® Energizer alkaline # 522 ®...
-
Page 7: Parts
Parts Parts Ref. Part No. Description 24B563 DATATRAK module 24A032 SWITCH, reed assembly 17S511 BRACKET, motor sensor ----- SCREW, machine phillips panhead; #6-32 UNC ----- NUT, hex; #6-32 UNC 19Y733 BRACKET, motor sensor 7 15V262 LABEL, safety (not shown; located on the bottom of the DataTrack module (ref. -
Page 8: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
