Instructions - - Parts List
AIR-DRIVEN, STAINLESS STEEL
Agitators
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for Table of Contents.
MODEL 222695
For 5-gallon pails
MODEL 204536
For 5-gallon pails
*MODEL 224571
For 5-gallon pails
*MODEL 224572
For 10-gallon pails
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440- -1441
Copyright 1995, Graco Inc. is registered to I.S. EN ISO 9001
01180
204536
222695
*
306565J
01181
01182
224572
II 1/2 G T6
2575
ITS03ATEX11226
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 222695
Summary of Contents for Graco 222695
- Page 1 For 5-gallon pails *MODEL 224572 01181 For 10-gallon pails 01180 01182 204536 224572 222695 II 1/2 G T6 2575 GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440- -1441 ITS03ATEX11226 Copyright 1995, Graco Inc. is registered to I.S. EN ISO 9001...
-
Page 2: Table Of Contents
D This equipment is for professional use only. D Read all instruction manuals, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are not sure, call Graco Technical Assis- tance at 1--800--543--0339. -
Page 3: Warning
WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and re- sult in a fire or explosion and serious injury. D Ground the equipment and the object being sprayed. Refer to Grounding on page 4. D If there is any static sparking or you feel an electric shock while using this equipment, stop spray- ing immediately. -
Page 4: Installation
(2) 1/8 npt inlet. See Fig. 2. Screw the elbow air line filter fitting (14b) into the 1/8 npt air supply manifold outlet. mix tank Model 222695 air regulator (reference only) and gauge Screw the air hose coupling (B) into the needle valve’s (2) 1/8 npt inlet. -
Page 5: Operation
208391 3/8 npt(m) x 3/8 npt(f) 208392 3/8 npt(f) x 1/4 npt(m) 208393 3/8 npt(m) x 3/8 npt(m) Air line Air hose coupling Air hose swivel stud Needle valve Muffler 14a Straight fitting 14b Elbow fitting 01180 01181 Model 222695 Model 204536 Fig. 2 306565... -
Page 6: Service
D If the unit requires more than installation of a WARNING service kit, it is usually quickest and easiest to send the unit to the Graco distributor for repair or FIRE AND EXPLOSION HAZARD replacement. Do not use kerosene or other flammable solvents to flush the air motor. - Page 7 Notes head.notes 306565...
-
Page 8: Parts Drawing
Includes items 2 to 12 MODEL 204536 ONLY Ref. No. 14 12 or 13 Tube Assembly Includes items 14a to 14c 01184 MODEL 222695 ONLY Ref. No. 15 Hose 01185 Apply medium grade sealant to external threads. 01183 Press fit. 306565... -
Page 9: Parts List
Part No. Description Qty. 224571 AGITATOR ASSEMBLY; 187265 SHAFT, agitator; SST; Includes items 2 to 12 Model 204536 and 222695 only 205528 NEEDLE VALVE ASSEMBLY; 187266 SHAFT, agitator; SST; Includes items 2a to 2f Model 224572 only 2a{ 166530 S NEEDLE, valve 224953 TUBE ASSEMBLY;... -
Page 10: Technical Data
Technical Data Maximum working pressure ....100 psi Noise level at 100 psi (0.7 MPa, 7 bar), at normal load, (0.7 MPa, 7 bar) at 800 rpm: Sound pressure . -
Page 11: Dimensions
Dimensions 3.12 in. 3.12 in. (80 mm) (80 mm) 13.25 in. (337 mm) 17.25 in. (433 mm) 01186 MODELS 204536 & 222695 Agitators for 5-gallon pail 01182 MODEL 224572 Agitator for 10-gallon pail 306565... -
Page 12: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
