Expanding blade mixer

Advertisement

Instructions
AIR DRIVEN
Expanding Blade Mixer
Expanding blade bung-mounted agitator for maintaining suspension and even mixing in
polyurethane spray foam resins and other industrial paints and coatings. For professional
use only.
Not approved for use in European explosive atmosphere locations.
Model 26C150
High Viscosity, up to 2000 centipoise
Model 26C818
Low Viscosity, up to 1000 centipoise
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment.
Save these instructions.
WARNING
FIRE AND EXPLOSION HAZARD
Use only non-flammable or water-based materials
with this equipment. Do not use materials having flash
points lower than 140° F (60° C). For more
information about your material, request Safety Data
Sheet (SDS) from the supplier.
3A5453D
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 26C150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco 26C150

  • Page 1 Expanding blade bung-mounted agitator for maintaining suspension and even mixing in polyurethane spray foam resins and other industrial paints and coatings. For professional use only. Not approved for use in European explosive atmosphere locations. Model 26C150 High Viscosity, up to 2000 centipoise Model 26C818 Low Viscosity, up to 1000 centipoise 100 psi (0.7 MPa, 7 bar) Maximum Working Pressure...
  • Page 2: Table Of Contents

    Check Fluid Viscosity ..... 8 Graco Information ......16 Maintenance .
  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 4 Warnings WARNING MOVING PARTS HAZARD Moving parts can pinch, cut or amputate fingers and other body parts. • Keep clear of moving parts. • Do not operate equipment with protective guards or covers removed. • Pressurized equipment can start without warning. Before checking, moving, or servicing equipment, follow the Pressure Relief Procedure and disconnect all power sources.
  • Page 5: Installation

    Air regulator and gauge (C): to control air motor and agitator speed. Connect ground clamp to a true earth ground. A ground wire and clamp, Part 238909, is available from Graco. Air line lubricator (D): downstream from the filter, install an air line lubricator for automatic air motor lubrication.
  • Page 6: Install The Agitator

    Installation Install the Agitator 2. To install the agitator on the container cover, drop the folding blade sections through the drum bung hole, then screw the bung adapter into the bung hole. See Dimensions, page 14. NOTE: During installation, if resistance is felt from the blades contacting the container bottom, continue to To prevent fire and explosion from sparks due to gently screw the bung adapter into the drum.
  • Page 7 Installation Angled Adapter If the agitator is used on a drum with an off-center bung and the blades would contact the side of the drum, the angled adapter must be used to avoid this contact. 1. Thread the locking ring (16H295) onto the angled adapter (16H294) by hand, as far as it will go.
  • Page 8: Operation

    Operation Operation NOTE: For best performance, ensure the shaft and blades are spinning counter-clockwise when viewed from above. The direction of rotation can be changed by reversing the position of the air inlet and muffler on the motor. To avoid personal injury due to moving parts, never operate the agitator outside of a drum.
  • Page 9: Maintenance

    Maintenance Maintenance Repair Lubricate the Air Motor NOTICE Not lubricating the air motor will cause air motor failure. If an air line lubricator is not installed, the air motor must be manually lubricated every 8 hours. Lubricate the agitator air motor by placing 10 to 20 drops of SAE #10 Flush the Air Motor lightweight oil in the motor’s air inlet.
  • Page 10: Service

    If the air motor (1) requires more than installation of (8) on the coupler. a service kit, it is usually quickest and easiest to send it to the Graco distributor for repair or 4. Slide the shaft off (2). replacement.
  • Page 11 Repair 3A5453D...
  • Page 12: Parts

    Parts Parts Torque to 65 in-lb (7.3 N•m). Torque to 80 in-lb (9 N•m). 3A5453D...
  • Page 13: Accessories

    24D687 ADAPTER, bung, double; includes * Air Motor Repair Kits may be purchased 3 setscrews (Item 9) and ground separately. Order part 224954 for Model 26C150 screw (Item 15) (high viscosity) or part 207335 for Model 26C818 17V032 HUB, assembly, with 3.5 in.
  • Page 14: Dimensions

    Dimensions Dimensions 2 in. Bung Adapter Dimension Model 26C150 (high viscosity) Model 26C818 (low viscosity) 5.1 in. (130 mm) 4.2 in. (107 mm) C (Minimum) 33 in. (838 mm) 33 in. (838 mm) D (Maximum) 35.1 in. (891 mm) 35.1 in. (891 mm) 1-1/2 in.
  • Page 15: Technical Specifications

    Sound power 80 dB(A) @ 100 psi (0.7 MPa, 7 bar) Sound pressure measured 3.28 feet (1 meter) from equipment. Sound power measured per ISO-9614-2. Air Driven Expanding Blade Mixer Model 26C150 High Viscosity Metric Maximum working pressure 100 psi 0.7 MPa, 7 bar...
  • Page 16: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
