- Page 1 English English SUITES & STOVES SUITES & STOVES Evoflame & E-Smart Evoflame & E-Smart INSTRUCTION MANUAL INSTRUCTION MANUAL Aaren Aaren Empire 2 Empire 2 Kalmar Kalmar Banff Banff EV8S EV8S Kibo Kibo Bergen Bergen Gilmore 6 Gilmore 6 Midori Midori...
-
Page 2: Table Of Contents
Front & Side Glass Installation................30 Applies to; Applies to; Aaren / Bergen / Kalmar / Kibo / Midori / Nessa / Banff / Aaren / Bergen / Kalmar / Kibo / Midori / Nessa / Banff / EV8S / Halmstad / Tuva... -
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances. -
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual. -
Page 5: Components For Suites And Stoves
EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4... -
Page 6: App Instructions
APP INSTRUCTIONS APP INSTRUCTIONS E-Touch & E-Smart Cloud E-Touch & E-Smart Cloud EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4... -
Page 7: E-Touch App Instructions (Evoflame Models)
E-TOUCH APP INSTRUCTIONS (EVOFLAME MODELS) The E-Touch app is a Bluetooth app that can be used with both smart phones and tablet The E-Touch app is a Bluetooth app that can be used with both smart phones and tablet devices, and is available on both the Apple App Store and Google Play Store. devices, and is available on both the Apple App Store and Google Play Store. - Page 8 NAMING YOUR FIRE Single press on the Gear Symbol in Single press on the Gear Symbol in Single press on the Modify Name Single press on the Modify Name the top right of the Home Page. the top right of the Home Page. option.
- Page 9 CHANGING LANGUAGE & UNITS Single press the Go Back button in Single press the Go Back button in Single press on the Setting button. Single press on the Setting button. the top left of the Home Page. the top left of the Home Page. You can now choose from English, You can now choose from English, To return to the Fire Connection...
- Page 10 PROGRAMMING THE TIMER Single press the Time Set button Single press the Time Set button There are two types of timer you There are two types of timer you on the Home Page to begin on the Home Page to begin can programme.
- Page 11 Scroll down the page to select either Heat Scroll down the page to select either Heat The Week/Common Mode Page will now The Week/Common Mode Page will now Low, or Heat High. Low, or Heat High. display your chosen settings. display your chosen settings.
-
Page 12: E-Smart Cloud App Instructions (E-Smart Models)
E-SMART CLOUD APP INSTRUCTIONS (E-SMART MODELS) The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet devices, and is available on both the Apple App Store and Google Play Store. - Page 13 CONTROL OVERVIEW To adjust the desired temperature of your fire ensure that the heater is selected on the To adjust the desired temperature of your fire ensure that the heater is selected on the Home Page in the previous step. Then press, hold, and rotate the temperature dial to set Home Page in the previous step.
- Page 14 PROGRAMMING THE TIMER Single press the clock icon on the Home Single press the clock icon on the Home Input your desired time in the Time box, Input your desired time in the Time box, Page to begin programming the Timer. Page to begin programming the Timer.
-
Page 15: Pairing With Amazon Alexa
Single press Search and type in Single press Search and type in Now on the Evonicfires Halo skill page Now on the Evonicfires Halo skill page evonicfires. Select the Evonicfires Halo evonicfires. Select the Evonicfires Halo... - Page 16 Enter the log in details that you Enter the log in details that you After a few moments your account will After a few moments your account will previously entered in the app set up previously entered in the app set up be linked, once this is done you can be linked, once this is done you can process, and single press Log In.
- Page 17 ALEXA COMMANDS When using Alexa to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Turning the appliance On and Off. “Alexa, turn fire on.” “Alexa, turn fire off.” Turning the heater On and Off. “Alexa, set fire heater to auto.”...
-
Page 18: Pairing With Google Home
PAIRING WITH GOOGLE HOME Once your fire is installed, and switched Once your fire is installed, and switched Single press Set up Device on the pop Single press Set up Device on the pop on, download and open the Google on, download and open the Google up list. - Page 19 Type in Evonic Fires, single press Type in Evonic Fires, single press Once in the evoflame log in page, enter Once in the evoflame log in page, enter search and then select the Evonic Fires search and then select the Evonic Fires the log in details that you previously log in details that you previously E-Smart icon.
- Page 20 GOOGLE HOME COMMANDS When using Google Home to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Please note that the Google Home app cannot control the heater in the appliance. Turning the appliance On and Off.
-
Page 21: Installation
INSTALLATION INSTALLATION EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4... -
Page 22: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is a Gilmour 7, however the same processes apply to all Suites. Scan the QR code for more detailed specification drawings. EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4... - Page 23 MODEL DIMENSIONS Model Width Height Depth Overall unit Overall unit With Riser / Opening Overall unit Bench (C) Aaren 845mm 687mm 457mm 360mm Banff 460mm 670mm 310mm 355mm Bergen 1475mm 615mm 355mm 357mm Bonham 7 1120mm 2027mm 2285mm 285mm 276mm...
-
Page 24: Installation Wall Mounted Suites
INSTALLATION INSTALLATION Wall Mounted Suites Wall Mounted Suites Aaren Aaren Compton 1000 Compton 1000 Kalmar Kalmar Bergen Bergen Empire 2 Empire 2 Midori Midori Bonham 7 Bonham 7 Gilmour 6 Gilmour 6 Nessa Nessa Bonham 9 Bonham 9 Gilmour 7... - Page 25 INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • The appliance must never be installed in front of an electrical socket. • The appliance must not be installed anywhere that it may come into contact with water, i.e.
- Page 26 TOOLS REQUIRED • Tape Measure • Drill Bit • Pencil • Wall Plugs (Masonry type supplied) • Spirit Level • Wall Screws (Masonry type supplied) • Screwdriver • Stud Detector (For plasterboard • PZ2 Screw Bit installations only) • Wall Anchors (For plasterboard installations only.
- Page 27 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
-
Page 28: Installation (Suites With Risers And Stoves)
INSTALLATION INSTALLATION Suites with Risers & Stoves Suites with Risers & Stoves Banff Banff Gilmour 6 Gilmour 6 Halmstad Halmstad Bonham 7 Bonham 7 Gilmour 7 Gilmour 7 Kalmar Kalmar Bonham 9 Bonham 9 Gilmour 9 Gilmour 9 Kibo Kibo Bonham 10 Bonham 10 Gilmour 10... - Page 29 INSTALLATION INSTALLATION REQUIREMENTS Before positioning the appliance please read and take into account the following important requirements; • The appliance must not be located anywhere that it may come into contact with water, i.e. a bathroom. • This appliance is only suitable for indoor use, do not use outdoors. •...
-
Page 30: Front & Side Glass Installation
FRONT AND SIDE GLASS FRONT AND SIDE GLASS INSTALLATION INSTALLATION Pivot Install Slotted Install Slide Install Aaren Aaren Banff Banff Halden Halden Bergen Bergen EV8S EV8S Kalmar Kalmar Halmstad Halmstad Kibo Kibo Tuva Tuva Midori Midori Nessa Nessa EVONIC - 104 INSTRUCTION MANUAL ISS. 4... - Page 31 PIVOT INSTALL The pivot install of the front glass applies to the Aaren, Bergen, Kalmar, Kibo, Midori, and Nessa. The model shown in this example is an E1030, but the same process applies to all six models. Unscrew and remove the top and bottom glass retainer panels.
- Page 32 Apply the Suction Lifter to the glass and apply the glass to the bottom edge first, then pivot into the appliance. The top and bottom glass retainers can now be replaced on the appliance. EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS.
- Page 33 SLOTTED INSTALL The slotted install of the front glass applies to the Banff, EV8S, Halmstad, and Tuva. The model shown in this example is the Halmstad, but the same process applies to all four models. To install the front glass first locate the four keyhole slots on the front of the appliance, and the four screws on the back of the front glass.
- Page 34 SLIDE INSTALL The sliding install of the front glass applies only to the Halden model. To remove the glass from the Halden model, first slide the lid back slightly, then lift. Now you can slide the glass vertically out of the appliance. EVONIC - 104 INSTRUCTION MANUAL ISS.
-
Page 35: Log Layouts
LOG LAYOUTS LOG LAYOUTS Suites & Stoves Suites & Stoves EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4... - Page 36 1 x Small Woodland / Silver Birch 1 x Tuva Log Set Aaren / Banff / Compton 2 / Empire 2 / Halden / Tuva EV8S / Halmstad / Midori / Nessa / Nimbus...
- Page 37 1 x Small Legacy Log Set Bonham 7 / Gilmour 6 / Gilmour 7 1 x Large Legacy Log Set Bonham 9 / Bonham 10 / Gilmour 9 / Gilmour 10 1 x Small Split Woodland / Silver Birch Kalmar EVONIC - 104 INSTRUCTION MANUAL ISS.
-
Page 38: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Suites & Stoves Suites & Stoves EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4... - Page 39 Evoflame Only - LED Strip Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 25 of this instruction manual for the new method.
- Page 40 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
