INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION IN CASE
OF FUTURE MAINTENANCE
E1030DS & E810DS -
Instruction Guide
Important Safety Information
Always read this manual first before attempting to install or use this
fireplace. For your safety, always comply with all warnings and safety
Instructions contained in this manual to prevent personal injury or property
damage.
Please Note: This product is for well insulated spaces or
occasional use.
English
SERIAL NUMBER LABEL
E-Series-180724
Advertisement
Related Manuals for Evonicfires E1030DS
Summary of Contents for Evonicfires E1030DS
- Page 1 INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION IN CASE OF FUTURE MAINTENANCE E1030DS & E810DS - Instruction Guide Important Safety Information Always read this manual first before attempting to install or use this fireplace. For your safety, always comply with all warnings and safety Instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
Warranty welcome to evonicfires evonicfires is an award-winning brand of CK Fires Ltd, situated just outside Stratford- upon-Avon, we manufacture a range of British built electric fires and are considered as one of the most technically advanced manufacturers in the world, with optional... -
Page 3: Electrical Safety
ELECTRICAL SAFETY: When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: ① Read all instructions before using this electric fireplace. ② This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. - Page 4 ⑬ Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage to the heater. ⑭ To prevent a possible fire, do not block air intakes or exhaust in any manner.
-
Page 5: Important Instructions
IMPORTANT INSTRUCTIONS: Please read these instructions before installation or use and keep this booklet handy for future reference. All Evonic fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: EN 55014-1:2006 + A2:2011 Electromagnetic compatibility. - Page 6 General Warnings: Never leave children unsupervised with an unguarded heater. Never obstruct or cover the heater outlet. Never install or use this product where it may come in contact with water i.e. a bathroom or wet room. Never use aerosols or steam cleaners near this product. Never route the electric cable near the heater outlet.
- Page 7 This appliance must be serviced every 12 months. Warning: Before carrying out any repairs or servicing, ensure that the power supply cord is removed from the mains supply. Technical Specification MODEL WIDTH DEPTH HEIGHT e1030DS 1010mm 500mm 556mm e810ds 803mm 500mm 1208mm...
-
Page 8: Installation Method
Installation Method This product is designed to be assembled into our E-mod installation units or an existing flue or suitable wall space. Please seek advice from a professional, with reference to the structural integrity of the installation site. if the products is to be installed into a open chimney or flue, it is important that the chimney/flue is blocked off to prevent any up/ down draughts and falling debris which could restrict and alter the airflow to the product. - Page 9 Fig 2 shows the fire fitted into an E-mod assembly. Identified are the plaster kit sides, and how they are used to support the body of the fire in place. Fig 2. Fig 3 indicates the top section of the plaster kit.
- Page 10 Installation Method: PLEASE NOTE: Due to the design of the Stora/Lindstrom, it may be advised to add additional support from the bottom of the fire using an appropriate method. The diagram below shows an example of how this would be achieved—using breeze blocks positioned to the extreme left and right of the fire will give ample support whilst still allowing the ventilation slots to remain clear and functional.
-
Page 11: Log Set Guidance
Log Set Guidance Please Note: The images shown are suggested Log layouts, the log sets can be arranged to personal preference. MODEL LOG LAYOUT/QUANTITY E1030DS E1000 Log Set X 5 E810DS E700 Log Set X 4... - Page 12 E-Touch & App Template The appliance is operated by the e-touch App, the main standby power switch to the e-series product is located to the right of the heater outlet, which is marked with a light bulb image, to activate the product, this switch must be switch to the “ON”...
-
Page 13: Glass Removal
Glass Removal: 1. Remove the 2 screws located in the bottom glass retaining bar. Repeat this process on either side of the fire 2. Remove the bottom glass retaining bar. Again, repeat this on both sides of the fire. 3. Remove the glass by pulling the second retaining bar away from the body of the fire. - Page 14 Troubleshooting Flow Chart: Problem Possible Cause Solution Ribbons are statically connected to Spray some anti-static spray beneath glass. the tray. Check the correct aperture has been Installation airflow restricted. adhered to when installing— Recommended clearance is 100mm. Flames not working correctly Blower clogged.
- Page 15 Problem Possible Cause Solution Fan unbalanced. Adjust fan to stop catching on the case. If problem persists replacement fan unit maybe required. Adjust fan to stop catching on the case Fan catching on housing. Noisy Heater Fan clogged. Fan requires cleaning out. If problem persists a replacement fan may be required.
- Page 16 Problem Possible Cause Solution Loose connection or disconnected Check all connections on LED’s wire. LED shorting out Check location of short—Replace LED No lights strip if necessary. LED blown LED strip needs replacing. Blown driver on PCB PCB needs replacing. Timer has been accidentally set.
-
Page 17: Warranty
This warranty is in addition to and does not affect the purchasers statutory rights of consumers. Registering product: To register a product please visit: www.evonicfires.co.uk and complete the fields required under the Register a Product Section. By registering your appliance, an extra 12...
