- Page 1 MR415 ■ AC/DC CURRENT PROBE MR416 ENGLISH User Manual...
- Page 2 Statement of Compliance ® ® Chauvin Arnoux , Inc. d.b.a. AEMC Instruments certifies that this instrument has been calibrated using standards and instruments traceable to international standards. We guarantee that at the time of shipping your instrument has met its published specifications.
-
Page 3: Table Of Contents
CONTENTS 1 DESCRIPTION ....................7 1.1 Interface ........................8 2 OPERATION ....................9 2.1 Battery Installation ....................9 2.2 External Power (Optional)..................9 2.3 Turning ON the Instrument .................. 10 2.4 Auto Standby ......................10 2.5 DC Zero Adjustment .................... 10 2.6 Measurements ..................... - Page 4 Thank you for purchasing the Current Probe MR415 or MR416. For best results from your instrument and for your safety, read the following operating instructions carefully and comply with the precautions for use. This instrument is compliant with the IEC 61010-2-032 safety standard for voltages of 300V with respect to earth in measurement category IV, or 600V in category III.
- Page 5 PRECAUTIONS FOR USE These instructions are intended to ensure the safety of users and proper operation of the instrument. Failure to observe these safety instructions may result in electric shock, fire, explosion, and destruction of the instrument and/or installations. The operator and/or the responsible authority must carefully read and clearly ...
- Page 6 RECEIVING YOUR SHIPMENT Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify your distributor of any missing items. If the equipment appears to be damaged, file a claim immediately with the carrier and notify your distributor at once, giving a detailed description of any damage.
-
Page 7: Description
1 DESCRIPTION The Models MR415 and MR416 are clamp-on current probes that measure DC currents up to 600A, AC currents up to 400A (600A peak), and combined AC+DC currents without opening the circuit in which the currents flow. They indicate the shape and amplitude of the current measured in the form of a voltage. -
Page 8: Interface
1.1 Interface Figure 1 (MR415 shown) Item Function Fixed (non-mobile) jaw Banana plugs (4mm) Arrow indicating current flow direction DC Zero button OL (overload) and ON indicators. ON is green when Auto Standby is enabled, yellow when it disabled. Slide switch (2-position for MR415, 3-position for MR416) USB port Trigger Hand guard... -
Page 9: Operation
2 OPERATION 2.1 Battery Installation Before changing batteries: set the switch to OFF and remove the clamp from the circuit under measurement. Using a screwdriver, remove the battery compartment cover (1) from the back of the housing (see Figure 2). Connect the battery to the snap-on connector (2), observing polarity. -
Page 10: Turning On The Instrument
2.3 Turning ON the Instrument Turn on the clamp by pushing the slide switch to the 1mV/A or 10mV/A setting: 1mV/A corresponds to the 600A range (MR415 and MR416) 10mV/A corresponds to the 60A range (MR416) The green ON indicator should light up: If indicator blinks, less than 4 hours of battery life remains ... -
Page 11: Measurements
2.6 Measurements 2.6.1 Making a Measurement After adjusting DC Zero: Press the clamp trigger to open the jaws. Clamp the jaws around the conductor to be measured. Use the centering marks on the jaws to position the clamp around the conductor. If the measurement is to be used in a power calculation, ensure the arrow on the clamp jaws (see Figure 1) points in the direction of the current flow: source... -
Page 12: Specifications
3 SPECIFICATIONS 3.1 Reference Conditions Quantities of Influence Reference Conditions Temperature 73°F ± 8°F (23°C ± 5°C) Relative humidity 20 to 75 % RH Position of the conductor Centered on the marks on the jaws Measurement frequency DC to 65Hz sine wave External electrical field zero External DC magnetic field (earth) - Page 13 Typical amplitude error curve at 60Hz Error (%) Current (A) Typical amplitude error curve in DC Error (%) Current (A) Current Probe Models MR415/416...
-
Page 14: Frequency Specifications, 1Mv/A Sensitivity
Typical phase error curve at 60Hz Phase shift (°) Current (A) 3.2.2 Frequency Specifications, 1mV/A Sensitivity Bandwidth -3dB: DC to 30kHz Frequency 50Hz 400Hz 1kHz 10kHz Insertion impedance <0.01mΩ 0.01mΩ 0.12mΩ 2.8mΩ Typical amplitude error versus frequency curve at 100A Error (%) Frequency (Hz) -
Page 15: Electrical Specifications, 10Mv/A Sensitivity (Mr416)
Typical phase versus frequency error curve at 100A Phase shift (°) Frequency (Hz) 3.2.3 Electrical Specifications, 10mV/A Sensitivity (MR416) Output impedance: 215Ω Specified 0.5 to 30A 30 to 40A 40 to 60A AC/DC AC/DC Measurement range Intrinsic uncertainty ≤±(3%R + 5mV) ≤±1.5%R ≤±1.5%R Phase error (45 to 65Hz) - Page 16 Typical amplitude error vs current curve at 60Hz Error (%) Current (A) Typical amplitude error vs current curve in DC Error (%) Current (A) Current Probe Models MR415/416...
-
Page 17: Frequency Specifications, 10Mv/A Sensitivity (Mr416)
Typical phase vs current error curve at 60Hz Phase shift (°) Current (A) 3.2.4 Frequency Specifications, 1mV/A Sensitivity Bandwidth -3dB: DC to 30kHz Frequency 50Hz 400Hz 1kHz 10kHz Insertion impedance <0.01mΩ 0.01mΩ 0.12mΩ 2.8mΩ Typical amplitude error versus frequency curve at 100A Error (%) Frequency (Hz) -
Page 18: Operating Limits
Typical phase versus frequency error curve at 100A Phase shift (°) Frequency (Hz) 3.3 Operating Limits In DC: 3000A permanent In AC: 1000A permanent up to 1kHz from 1kHz, I = 1000/f (kHz) Conductor temperature: ≤ 194°F (90°C), 230°F (110°C) peak ... -
Page 19: Variations In The Range Of Use
3.4 Variations in the Range of Use Error in % of reading Quantity of influence Range of influence Typical Maximum 14 to 131°F Temperature 0.3% (‑10 to + 55°C) Relative humidity 10 to 85% RH 0.5% 10 to 400Hz Frequency 400Hz to 7kHz 3.5% 7 to 30kHz... -
Page 20: Environmental Conditions
3.6 Environmental Conditions The instrument must be used in the following environmental conditions. °C 1 = Range of reference 2 = Operating range 3 = Storage range Indoor use Degree of pollution: 2 Altitude: < 6500’ (2000m) Transport altitude: ≤ 40,000’ (12,000m) Current Probe Models MR415/416... -
Page 21: Mechanical Specifications
3.7 Mechanical Specifications Dimensions (L x W x H): 8.8” x 3.8” x 1.7” (224 x 97 x 44mm) Weight: approximately 15.5oz (440g) Cable: 4.9’ (1.50m) Clamping diameter: 1.2” (30mm) in diameter, two cables 0.94” (24mm) in diameter, one 1.97” x 0.39”... -
Page 22: Maintenance
4 MAINTENANCE Except for the battery, the instrument contains no parts that can be replaced by personnel who have not been specially trained and accredited. Any unauthorized repair or replacement of a part by an "equivalent" may gravely impair safety. 4.1 Cleaning Disconnect the instrument completely. -
Page 23: Repair And Calibration
If the instrument is returned for calibration, we need to know if you want a standard calibration, or a calibration traceable to N.I.S.T. (includes calibration certificate plus recorded calibration data). ® ® Chauvin Arnoux , Inc. d.b.a. AEMC Instruments 15 Faraday Drive Dover, NH 03820 USA Tel: (800) 945-2362 (Ext. -
Page 24: Limited Warranty
CSA Form. Please write the CSA# on the outside of the shipping container. Return the instrument, postage or shipment pre-paid to: ® ® Chauvin Arnoux , Inc. d.b.a. AEMC Instruments 15 Faraday Drive • Dover, NH 03820 USA Tel: (800) 945-2362 (Ext. - Page 25 NOTES Current Probe Models MR415/416...
