Task Force Tips HURRICANE Instructions For Installation, Safe Operation And Maintenance page 34

9.6 ELEVATION CHAIN DRIVE ASSEMBLY
9.7 GEAR MOTOR ASSEMBLY
#
1
2
3
4
5
6
7
8
9
©Copyright Task Force Tips, Inc. 2008-2014
1
# DESCRIPTION
1 HOUSING
2 BUSHING - SHAFT
3 BUSHING - DRIVE
4 ROLLER CHAIN RING
5 SPROCKET - SLAVE
6 SPROCKET - DRIVE
7 BUSHING - MOTOR
8 COVER
9 1/4-28 x ½ BHCS
DESCRIPTION
6-32 x 5/16 LONG SHCS WITH HEAD SEAL
CUP SEAL 1.0625 x .5625 x 1/4
MOTOR SOCKET
O-RING-018
CONDUIT FITTING
HOSE - 3/8" ID PUSH-LOK
O-RING-038
GEAR MOTOR WITH ENCODER
ENCLOSURE
2 4 5
3 6
QTY PART #
1 X250
1 X251
1 X252
1 X255
1 X254
1 X253
1 X256
1 X257
1 VT25-28BH500
QTY
4
1
1
1
1
1
1
1
1
34
8
7
PART #
VT06S32SH312
Y4620
Y4615
VO-018
Y5213
Y5250
VO-038
Y4611
Y4616
LIX-300 April 29, 2014 Rev18
9
