# DESCRIPTION
1 SHAFT NUT
2 SNAP RING
3 BEARING
4 SPACER
5 12 DP WORM
6 BUSHING
7 BOOT
8 GREASE FITTING 1/4-28
9 HEX CAP
10 3/8-16 X 5/8 SOCKET HEAD SCREW
11 3/8-16 X 7/8 SOCKET HEAD SCREW
12 TOMBSTONE
13 PEG
14 BELL/BIG BEND
15 1/4"NPT HEX HEAD PLUG
16 KEY
17 HANDWHEEL SUBASSEMBLY
18 CRANK SUBASSEMBLY
19 3/8-24 X 5/16 SOCKET SET SCREW
20 3/8-24 X 3/8 SOCKET SET SCREW
21 DRIVE SHAFT
22 1/4-20 X 1/2 BUTTON HEAD SCREW
23 SIDE TO SIDE HANDWHEEL SUBASSEMBLY 1
24 CRANK WITH KNOB SUBASSEMBLY
25 5/16" TORLON BALL (49) PER RACE
©Copyright Task Force Tips, Inc. 2008-2014
QTY PART # # DESCRIPTION
1 X210
BASE CODE-RPF 4"
2 VR4220
BASE SHORT CODE-RPF 4"
26
2 VM4252
BASE CODE-RLF 3"
2 X235
BASE QUICK CONNECT 4.5"NHF SUBASSY
2 X220
VO-RING-244
27
1 X230
VO-RING-236
1 X240 4" MONITOR BASE CLAMP
28
2 VT25-28ZERK 3" MONITOR BASE CLAMP
1 X355 29 WASHER
2 VT37-16SH625 30 10-24 X 1 1/4 SOCKET HEAD SCREW
1 VT37-16SH875 31 CYLINDER NUT
1 X365 32 DRAIN VALVE SUBASSEMBLY
1 X362 33 VO-RING-130
1 X806 34 VO-RING-350
1 VFHP2M 35 1/4-28 X 3/8 SOCKET SET SCREW
2 X225 36 3/8-24 X 5/16 SET SCREW FLAT POINT
1 X815 37 HEADED BUSHING
1 X815-Z 38 SHAFT SPRING STAINLESS
2 VT37-24SS312 39 WASHER ACETAL
5 VT37-24SS250 40 SPACER
1 Y4160 41 WASHER
2 VT25-20BH500 42 SMALLEY RING
Y4940 43 COVER PLATE
1 A1623 44 1/4-28 X 1/2 BUTTON HEAD SCREW
136 VB.312TO 45 O-RING-241
46 5/16" SS BALL
47 ELBOW ALUM 2.5"
29
* - CONSULT FACTORY FOR SPECIAL THREADS
QTY PART #
Y4400A
Y4401A
1
Y4405A
Y4960
VO-244
1
VO-236
Y4435
2
Y4436
2 VW360X200-04
2 VT10-24SH1.2
2 Y4437
1 X840
1 VO-130
1 VO-350
2 VT25-28SS375
2 VT37F24SS312
1 Y4141
1 Y4159
1 VW1.0X759-04
1 Y4150
1 VW97X595-048
1 VR4365
1 Y4164
3 VT25-28BH500
1 VO-241
38 VB.312
1 X333*
