Task Force Tips HURRICANE Instructions For Installation, Safe Operation And Maintenance page 27

#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
©Copyright Task Force Tips, Inc. 2008-2014
DESCRIPTION
SHAFT NUT
SNAP RING
BEARING
SPACER
12 DP WORM
BUSHING
BOOT
GREASE FITTING 1/4-28
HEX CAP
3/8-16 X 5/8 SOCKET HEAD SCREW
3/8-16 X 7/8 SOCKET HEAD SCREW
TOMBSTONE
PEG
EXTENDED BEND
1/4"NPT HEX HEAD PLUG
KEY
HANDWHEEL SUBASSEMBLY
CRANK SUBASSEMBLY
3/8-24 X 3/8 SOCKET SET SCREW
CLEVIS PIN RETAINER
CLEVIS PIN 1/4 X 2
5/16" TORLON BALL (38) PER RACE
WEAR STRIP
CUP SEAL
FLANGE ALUM 3"ANSI/XF
TRUCK ADAPTER 3.0"NPTF
FLANGE ALUM 4"ANSI/XF
ROTATIONAL LOCK LEVER/PIN - ASSEMBLY
ROTATION LOCK LEVER SPRING
ROTATION LOCK INSERT
DRAIN VALVE SUBASSEMBLY
O-RING-130
O-RING-241
5/16" SS BALL
ELBOW ALUM 2.5"
* - CONSULT FACTORY FOR SPECIAL THREADS
QTY
1
1
1
2
1
1
1
2
1
2
1
1
1
1
1
1
1
1
4
1
1
114
1
1
1
1
1
1
1
1
1
38
1
27
PART #
X210
VR4220
VM4252
X235
X220
X230
X240
VT25-28ZERK
X355
VT37-16SH625
VT37-16SH875
X365
X362
X805-E
VFHP2M
X225
X815
X815-Z
VT37-24SS375
X137
X180
VB.312TO
X120
X125
X410-3ASA
X411PL
X414-4ASA
X821
X152
X170
X840
VO-130
VO-241
VB.312
X339*
LIX-300 April 29, 2014 Rev18
