Pixelstrip 20
V1
Order code: 44501
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pixelstrip 20 and is the answer not in the manual?

Questions and answers

Summary of Contents for SHOWTEC Pixelstrip 20

  • Page 1 MANUAL ENGLISH Pixelstrip 20 Order code: 44501 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Pixelstrip 20 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Rigging .................................... 4 Return Procedure ................................5 Claims ....................................5 Description of the Device ..............................6 Overview ..................................6 Installation ................................... 7 Setup and Operation ................................ 7 Connecting Multiple Pixelstrips ...........................
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture will be returned in the original factory box and packing. Your shipment includes: ● Showtec Pixelstrip 20 ● CAT-5 data cable (1,3 m) ● User manual...
  • Page 4: Operating Determinations

    ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. ●...
  • Page 5: Rigging

    Please follow the European and national guidelines concerning rigging, trussing and all other safety issues. Improper installation can cause serious injuries and/or damage of property! Fig. 01 The Pixelstrip 20 can be mounted to any kind of truss with a clamp. Order code: 44501...
  • Page 6: Return Procedure

    Pixelstrip 20 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
  • Page 7: Description Of The Device

    ● Weight: 0,88 kg The Pixelstrip 20 is designed to be operated together with the Pixel Controller. Note: The Pixelstrip 20 is delivered without the Pixel Controller. You need to purchase it separately. 44502 – Pixelstrip 40 (100 cm) 44510 –...
  • Page 8: Installation

    The maximum length of your setup must not exceed 16 meters per controller (max. 4 meters per output)! It is possible to combine the Pixelstrip 20 (44501) and the Pixelstrip 40 (44502), if the 4-meter setup length limit is observed.
  • Page 9: How To Make A Data Cable

    Pixelstrip 20 How To Make a Data Cable A standard ETHERNET cable can be used to replace the data cable required to transmit the data. Please follow the instructions below in order to create an extra network cable. Take a standard network cable (CAT-5/ 5E /6) and connect it to the RJ45 connector, as shown in Fig. 04.
  • Page 10: Maintenance

    03) The electric power supply cables must not show any damages or material fatigue. The Pixelstrip 20 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the housing with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents.
  • Page 11: Product Specifications

    Pixelstrip 20 Product Specifications Model: Showtec Pixelstrip 20 Dimensions: 500 x 37 x 100 mm (LxWxH) Weight: 0,88 kg Light source: 20 x SMD5050 RGB LEDs (0,3 W) Pixel pitch: 25 mm Maximum cable length: 10 m (CAT-5/CAT-6) from the Pixel Controller to the...
