Summary of Contents for SHOWTEC Phantom 75 MKII Led Spot v1
- Page 1 MANUAL ENGLISH Phantom 75 MKII LED Spot V1 Ordercode: 40207 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Phantom 75 MKII LED Spot Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Features .................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec Phantom 75 MKII LED Spot IEC power cable (1,5 m) ... - Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Phantom 75 MKII LED Spot • The user is responsible for correct positioning and operating of the Phantom. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. • This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to earth. -
Page 6: Connection With The Mains
Phantom 75 MKII LED Spot The Phantom can be placed on a flat stage floor or mounted to any kind of truss with a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. Always check if the right color cable is connected to the right place. -
Page 7: Return Procedure
Phantom 75 MKII LED Spot Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Phantom 75 MKII LED Spot Description of the device Features The Phantom 75 MKII LED Spot is a moving head with high output and great effects. Input voltage: 100-240V AC, 50/60Hz Power consumption: 230W Light source: 1 x 75W White LED ... -
Page 9: Backside
Phantom 75 MKII LED Spot Backside Fig. 02 03) IEC 100-240V power connector IN 04) IEC 100-240V power connector OUT 05) Fuse F4A/250V 06) 3-pin DMX signal connector IN 07) 3-pin DMX signal connector OUT Installation Remove all packing materials from the Phantom 75 MKII LED Spot. Check if all foam and plastic padding is removed. -
Page 10: Control Modes
Phantom 75 MKII LED Spot Control Modes There are 4 modes: • Stand-alone (Auto) • Sound-controlled • Master/Slave • DMX-512 (8CH, 14CH) One Phantom (Auto) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). -
Page 11: Multiple Phantoms (Dmx Control)
Phantom 75 MKII LED Spot Multiple Phantoms (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Phantoms and other devices. 04) Link the units as shown in fig. -
Page 12: Fixture Linking
Phantom 75 MKII LED Spot Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 13: Control Panel
Phantom 75 MKII LED Spot The Phantom 75 MKII LED Spot can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) LCD display MODE button C) UP button D) DOWN button ENTER button Fig. -
Page 14: Menu Overview
Phantom 75 MKII LED Spot Menu Overview Ordercode: 40207... -
Page 15: Main Menu Options
Phantom 75 MKII LED Spot Main Menu Options DMX Address DMX-512 mode / Master-Slave mode / Auto / Sound-controlled mode Audio Sensitivity / Pan + Tilt/Reverse Pan + Tilt / Display/Reverse Display/ Pan + Tilt Angle System Info 1. DMX Addressing With this menu, you can set the DMX address of your Phantom 75 MKII LED Spot. -
Page 16: Dmx-512 Mode
Phantom 75 MKII LED Spot 2.1. DMX-512 Mode 01) Press the UP/DOWN buttons until the display shows: 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to choose one of the 2 channel modes: 8-channel mode or 14-channel mode. -
Page 17: Sound-Controlled Mode
Phantom 75 MKII LED Spot 2.4. Sound-controlled Mode 01) Press the UP/DOWN buttons until the display shows: 02) Press the ENTER button to activate the mode. 03) The device will now react to the beat of the background music. 3. Setup With this menu, you can adjust the settings of your Phantom 75 MKII LED Spot. -
Page 18: Screen Reverse
Phantom 75 MKII LED Spot 3.3. Screen Reverse 01) Press the UP/DOWN buttons to choose Screen Reverse. 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to choose ON/OFF and press the ENTER button to confirm your choice. 04) If you choose ON, the display will be reversed. -
Page 19: Dmx Channels
Phantom 75 MKII LED Spot DMX Channels 8 Channels Channel 1 – Horizontal movement (Pan) Move the slider up, in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 540°... -
Page 20: Channels
Phantom 75 MKII LED Spot 88-95 Gobo Shake 4 from slow to fast 96-103 Gobo Shake 3 from slow to fast 104-111 Gobo Shake 2 from slow to fast 112-119 Gobo Shake 1 from slow to fast 120-127 Open / White 128-191 Clockwise rotation (CW) rainbow effect from slow to fast 192-255... - Page 21 Phantom 75 MKII LED Spot 71-77 Split Color Yellow / Pink 78-84 Split Color Pink / Green 85-92 Split Color Green / Red 93-98 Split Color Red / Light Blue 99-105 Split Color Light Blue / Light Green 106-112 Split Color Light Green / Orange 113-119 Split Color Orange / Dark Blue 120-127...
- Page 22 Phantom 75 MKII LED Spot 56-87 No Function 88-95 No Function 96-103 Reset Pan after 3 seconds 104-111 Reset Tilt after 3 seconds 112-119 Reset Color wheel after 3 seconds 120-127 Reset Gobo wheel after 3 seconds 128-135 Reset Gobo rotation after 3 seconds 136-143 Reset Prism after 3 seconds 144-151...
-
Page 23: Maintenance
Phantom 75 MKII LED Spot Maintenance The operator has to make sure that safety-related and machine-technical installations are to be inspected by an expert after every year in the course of an acceptance test. The operator has to make sure that safety-related and machine-technical installations are to be inspected by a skilled person once a year. -
Page 24: Replacing A Gobo From The Rotating Gobo Wheel
Phantom 75 MKII LED Spot Replacing a Gobo From the Rotating Gobo Wheel 01) Disconnect mains power supply and set the switch to OFF. 02) Make sure that the gobo you want to insert has the same size. For the right size, see below. Gobo Size Fig. -
Page 25: Replacing A Gobo From The Rotating Gobo Wheel
Phantom 75 MKII LED Spot Replacing a Gobo From the Rotating Gobo Wheel Coated glass gobos are inserted with the coating against the rim of the holder (away from the spring). Textured gobos are inserted with the smooth side against the spring. This provides the best results when combining rotating gobos. -
Page 26: Troubleshooting
Suspect three potential problem areas as: the power supply, the LEDs, the fuse. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Phantom to your Showtec dealer. 03) The fuse. Replace the fuse. See page 22 for replacing the fuse. - Page 27 Phantom 75 MKII LED Spot Problem Probable cause(s) Remedy One or more No power to the fixture. ● Check if power is switched on and fixtures do not cables are plugged in. function at all Primary fuse blown. ● Replace fuse. Fixtures reset The controller is not connected.
-
Page 28: Product Specifications
Phantom 75 MKII LED Spot Product Specifications Model: Showtec Phantom 75 MKII LED Spot Input voltage: 100-240V AC, 50/60Hz Power consumption: 230W (full output) DMX linking: 30pcs Fuse: F4A/250V Dimensions: 330 x 245 x 445 mm (LxWxH) Weight: 11,4 kg... -
Page 29: Dimensions
Phantom 75 MKII LED Spot Dimensions Ordercode: 40207... -
Page 30: Notes
Phantom 75 MKII LED Spot Notes Ordercode: 40207... - Page 31 Phantom 75 MKII LED Spot Ordercode: 40207...
- Page 32 ©2016 Showtec...
