- Page 1 MANUAL ENGLISH Parcan 46 Pro Ordercode: 30257/30258 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Parcan 46 Pro Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Overview ..................................7 Lamp Housing ................................8 Installation ................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Parcan 46 Pro with Schuko power cable (0,8 m) ● Color frame ●... - Page 4 ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Parcan 46 Pro Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 1 meter. - Page 6 Parcan 46 Pro The Parcan can be mounted to any kind of truss with a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. Always check if the right color cable is connected to the right place. International EU Cable UK Cable...
-
Page 7: Return Procedure
Parcan 46 Pro Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Parcan 46 Pro Description of the device Features The Parcan 46 Pro is a theatre spotlight fixture with high output. ● Input voltage: 240V, 50Hz ● Power consumption: 90W ● Lamp socket: E27 ● Housing: Metal & flame retardant plastic ●... -
Page 9: Lamp Housing
Parcan 46 Pro Lamp Housing Fig. 02 07) Lamp socket E27 Installation Remove all packing materials from the Parcan 46 Pro. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 10: Installing The Lamp
Installing the Lamp The Showtec Parcan 46 Pro uses the Par 30 E27 Spot Osram lamp, 75W (ordercode 80120) and the Par 30 E27 Flood Osram lamp, 75W (ordercode 80121). Use only the appropriate lamp for your unit. Note that product versions, that use other lamps, may be offered in the future. -
Page 11: Set Up And Operation
Parcan 46 Pro Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connect the device to the main power supply. -
Page 12: Troubleshooting
04) If you are unable to determine the cause of the problem, do not open the Parcan, as this may damage the unit and the warranty will become void. 05) Return the device to your Showtec dealer. Problem Probable cause(s) Solution •... -
Page 13: Product Specifications
Parcan 46 Pro Product Specifications Model: Showtec Parcan 46 Pro Input voltage: 240V AC, 50Hz Power consumption: Dimensions: 315 x 194 x 240 mm (LxWxH) Weight: 1 kg Electro-mechanical effects: Allowed lamp models*: 80120 – Par 30 E27 Spot Osram 80121 –... -
Page 14: Dimensions
Parcan 46 Pro Dimensions Ordercode: 30257/30258... - Page 15 Parcan 46 Pro Ordercode: 30257/30258...
- Page 16 ©2017 Showtec...
