Cypress Semiconductor POWERPSOC CY3267 Quick Start Manual

CY3267 POWERPS
• Download and Install the latest kit
software and examples from
www.cypress.com/go/CY3267
• Mount the optical diffuser on the LED
daughter board. Connect the power supply
to the main board
• Connect the main board to the PC using the
USB cable provided with the kit
EVALUATION KIT QUICK START GUIDE
1
3
5
C LIGHTING
®
O
• Connect the CY3267 PowerPSoC
the LED daughter board; see the user guide
for instructions
• Touch the ON/OFF CapSense
toggle the LEDs. Touch the COLOR CapSense
button to cycle through colors
• Use the GUI installed on the PC to control
LEDs. See the user guide for more
information about the GUI
