b) an already test-flown model
- Assign the gyro outputs
- Learn the installed position
- Learn the centre and end-points
- Adjust the iGyro in flight using the gain control
- Fine-tune the individual axes if necessary
- Store the established gain value on a switch
As you can see, while you are carrying out basic adjustments to a new model, or
test-flying a new model without the gyro, no adjustments of any kind are required
at the iGyro SAT or the Pioneer. For this reason we start the set-up procedure in
the menu where the gyro outputs are assigned.
The Pioneer's gyro functions are identical to the settings in PowerBox PBR recei-
vers with an iGyro SAT connected. The only difference is that the Pioneer provides
nine gyro axes, whereas the PBR receivers provide six.
Start with setting up the iGyro as described in the iGyro SAT Instructions, starting
at Point 3.2.
Note: CORE and Jeti transmitter menus are arranged identically, and differ only
in their appearance and the method of operation using touch-screen or buttons.
The Pioneer's gyro functions are identical to the settings in PowerBox PBR recei-
vers with an iGyro SAT connected. The only difference is that the Pioneer provides
nine gyro axes, whereas the PBR receivers provide six.
Start with setting up the iGyro as described in the iGyro SAT Instructions, starting
at Point 3.2.
