2. BASIC SETTINGS

If you are not using an iGyro with the PowerBox Pioneer, only a few settings have
to be entered. You will find all the settings either in the transmitter menu (CORE,
Jeti) or the Mobile App and the PC program.
To access the menu on the PowerBox CORE transmitter, create any Teleme-
try widget for the Pioneer; you will then find the Menu button in the widget.
On a Jeti transmitter you will find the Jetibox point under Additional functions. Se-
lect this point, then select MX at far right. If you now press at the bottom, you will
find yourself in the Pioneer menu again.
a) Frame rate
This menu point allows you to set the servo signal repeat rate. If you are using older
analogue servos, use the 18 ms setting. For more recent digital servos the 12 ms
setting can be selected.
The default setting is 16 ms.
b) Capacity reset channel
The purpose of this function is to select the channel you wish to use for resetting
consumed battery capacity; the default setting is Channel 16. This channel resets
the consumed capacity as soon as the travel exceeds 100 %. You can use a switch
or button for this and reset the capacity every time you charge the batteries.
c) Reset Gyro
Selecting this function resets all gyro settings.
Caution: there is no security query for this function!
