Cable Tests
(continued)
Transmitted Frames
Cable Performance Test
Results
Received Frames
Errored Frames
Link-Remote Performance Tests
VoIP Performance Test
Fixed Settings
Frame Fill
Setup
Failure Threshold
Test
SignalTEK NT
User Guide
12
Count (0 to 10
Percentage (0 to 100% with colored bar indication - green if
100%, red if <100%)
Result
Pass (100%)
Fail (<100%)
12
Count (0 to 10
Percentage (0 to 100% with colored bar indication - green if
100%, red if <100%)
Result
Pass (100%)
Fail (<100%)
12
Count (0 to 10
Percentage (0 to 100% with colored bar indication. Green if
below threshold, red if > threshold)
Result
Pass (<threshold)
Fail (> threshold)
Frame size
Fixed 218 bytes
Random
Number of Simultaneous Calls
User-defined. (Range 1 to 10,000 . Default 100)
Equivalent Information Rate calculated and displayed
Duration
User-defined (hh:mm:ss upto 24 hours. Default 10 secs)
Number of frames (0 to 99. Default 0)
- Frames transmitted to Remote at calculated Frame Rate for
specified duration
- Frames looped back by Remote
- Received frames checked and counted
)
)
)
(continued)
156875 Iss 3
Page 43
