8.0 fi nish framing - after appliance installation fi nish framing - after appliance installation
EN
There are various methods to ventilate the enclosure. Refer to "installation planning" section. Only two options
are illustrated - installation option 2 and installation option 5.
The appliance must be installed at this point of framing. Appliance is not shown to better illustrate framing.
fl ush
Dynamic Heat Control™
front air outlet opening
L
D
note:
Finish framing must be built after appliance has been placed in its fi nal position and venting connected.
minimum framing
Ref
I
C
D
H
L
Q*
(Q x R)*
* ONLY APPLICABLE TO OPTION 2, 3 and 5 - Opening must be centered in enclosure on appliance. Dimensions represent
fi nished sizes and where applicable should be adjusted to include fi nish material thickness.
note:
The Elevation series requires a minimum enclosure height (as illustrated) measured from the bottom of the ap-
pliance. For temperature requirements, this area must be left unobstructed. Some venting confi gurations that
require more vertical rise will require a larger enclosure to provide minimum vertical clearance between vent pipes
and combustibles.
18
W415-2753 / A / 07.20.20
R
Q
H
I
C
D
EX36
39 3/4"
43 3/4"
Dynamic Heat Control™
side air outlet opening
L
D
22 1/4"
6"
72"
2" min and 3" max
112 sq. in.
R
Q
H
C
D
EX42
45 3/4"
47 3/4"
