AIR ANGLE GRINDER
MODEL NO: CAT122
PART NO: 3110878
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0810

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air CAT122 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke Air CAT122

  • Page 1 AIR ANGLE GRINDER MODEL NO: CAT122 PART NO: 3110878 OPERATION & MAINTENANCE INSTRUCTIONS LS0810...
  • Page 2: Environmental Protection

    A wide range of accessories are available, including Filter/Regulators, Lubricators, High Pressure Hoses (5 to 100 Metres), etc. Contact your CLARKE dealer for further information, or CLARKE International Sales Department on 01992 565 333. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 3: General Safety Rules

    GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way.
  • Page 4 10. Do not carry out any alterations or modifications to the air angle grinder. 11. Always disconnect from the air supply when: • Performing any maintenance • The air angle grinder is not in use. • The air angle grinder will be left unattended. •...
  • Page 5 OVERVIEW DESCRIPTION NO DESCRIPTION Throttle Lever Lock Wheel Guard Throttle Lever Grinding Disc Female Air Inlet (1/4” BSP) Main Body Side Handle Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 6: Air Supply

    AIR SUPPLY WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source for the air angle grinder. •...
  • Page 7: Before Use

    BEFORE USE FITTING THE SIDE HANDLE 1. Screw the side handle to the main body as shown. FITTING THE GRINDING DISC WARNING: ENSURE AIRLINE IS DISCONNECTED FROM TOOL. WARNING: WHEN FITTING DISCS, ALWAYS INSPECT FOR DAMAGE ETC, NEVER USE GRINDING DISCS IF THEY ARE CHIPPED OR CRACKED. 1.
  • Page 8: Connecting The Air Hose

    1. Remove the travel plug from the bottom of the air angle grinder as shown. 2. Pour 2-3 drops of CLARKE airline oil into the air inlet. This should be done regardless of whether or not a lubricated air supply is to be used.
  • Page 9: Disconnecting The Air Supply

    USING THE AIR ANGLE GRINDER 1. Connect airline and turn air supply 2. Hold firmly using both hands, right hand on motor body and left hand on handle. 3. To switch on, push throttle lever lock forward, at the same time depress throttle lever.
  • Page 10: Specifications

    1.96 kg NOTE: Please note that the details and specifications contained herein, are correct at the time of going to print. However CLARKE International reserve the right to change specifications Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 11: Maintenance

    DAILY • Drain water from air tank, air line and compressor. • Pour a few drops of CLARKE Air Line Oil, into the air inlet. This should be carried out regardless of whether or not the inline mini oiler is used.
  • Page 12: Vibration Emissions

    VIBRATION EMISSIONS Employers are advised to refer to the HSE publication “Guide for Employers”. All hand held power tools vibrate to some extent, and this vibration is transmitted to the operator via the handle, or hand used to steady the tool. Vibration from about 2 to 1500 hertz is potentially damaging and is most hazardous in the range from about 5 to 20 hertz.
  • Page 13 The graph on the right shows the vibration value against the maximum time the respective tool may be used, per day. The uncertainty factor should also be taken into account when assessing a risk. The two figures ‘a’ and ‘K’ may be added together and the resultant value used to assess the risk.
  • Page 14: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 15 NOTES Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
