Replacing SimMan 3G Left Leg with Trauma Leg
1
1. Remove the SimMan 3G default leg.
Open Torso skin and stomach foam as
shown in steps 1-3, page 4.
3
3. Carefully remove the left leg with cables
and tubes.
5
5. Insert the blood tube into the side
slot of the connector. Screw the
connector in place with one hand.
2
2. Unscrew hip joint connector. Remove
the leg cables/tubes from the connector.
4
4. Insert the Amputation or Gunshot leg
with blood tube into the leg socket.
6
6. Connect the
corresponding tube, as labelled inside
the torso.
7. Close the stomach foam and zip the
torso skin back into place.
6
leg tube to the
