- Page 1 Operating Instructions Universal Sample Pump Catalog No. 224-PCXR8M SKC Inc. 863 Valley View Road Eighty Four, PA 15330 Form #37729 Rev 0804...
-
Page 3: Table Of Contents
Table of Contents Description ................1 Performance Profile....................2 Operation ................4 High Flow Applications................... 4 Low Flow Single-tube Applications................. 9 Low Flow Multiple-tube Applications..............14 Maintenance ...............20 Pump Inlet Filter....................20 Battery Pack Care....................20 Replacing Battery Pack..................21 Service Policy ..............22 Parts Descriptions .............24 Replacement Parts.................... -
Page 5: Description
Description The PCXR8M Universal Sample Pump is a constant flow air sampler suitable for a broad range of applications. It is ideal for industrial hygiene studies as well as environmental testing. Durable RFI-shielded Case provides protection from radio frequency interference between 27 and 1000 MHz. -
Page 6: Performance Profile
Performance Profile Flow Range:......1000 to 3000 ml/min (5 to 500 ml/min requires adjustable low flow holder) Weight:........34 oz (964 gm) Dimensions:......5.1 x 4.7 x 1.9 in (13 x 11.9 x 4.8 cm) Compensation Range:.. - Page 7 50082-1; frequency range of the radiated susceptibility test was 27 MHz to 1000 MHz. CE marked. Intrinsic Safety:....MSHA approved to 30 CFR, section 18; approval no. 2G-4036-0. Tested for use in methane-air mixtures only. Intrinsic safety and other approvals may be void if SKC pumps are not repaired by SKC or authorized SKC repair centers. Replacing parts with non-SKC parts or parts not approved for use with this pump model can void intrinsic safety approvals and the manufacturer warranty.
-
Page 8: Operation
Start/Hold Key Mode Key SAMPLE PERIOD — MINUTES START FLOW BATTERY HOLD CHECK Set-up Key SET-UP MODE AIRCHEK SAMPLER MODEL 224-PCXR8M DIGIT DIGIT SELECT Digit Set/Pump Run Time Key PUMP TOTAL ELAPSED TIME TIME FLOW Digit Select/Total Elapsed Time Key... - Page 9 De-activating the Regulator To ensure the pump is set for high flow, remove the cap screw (Figure 1, #18) covering the regulator valve and turn the exposed screw clockwise until it stops. (Do not overtighten.) Replace the cap screw. The pump is now set for high flow.
- Page 10 Programming Delayed and Intermittent Sampling To enter Delayed Start Mode: From Hold, press Setup. Enter the number of minutes delay (up to 9999) before the sampling period begins by pressing Digit Select and Digit Set. Digit Select advances the flashing digit and Digit Set increases the value of the flashing digit.
- Page 11 Sampling For personal sampling, clip the sample collection medium to the worker in the breathing zone. Protect sample pump from weather when in use outdoors. Use of any device other than the approved battery pack to power the pump voids MSHA approval. While the LCD displays HOLD, start sampling by pressing Start/Hold. If a time delay has been programmed, DELAYED START will flash on the Clip sample medium to LCD and the amount of time remain- worker and pump to belt.
- Page 12 Sampling with Impingers When using impingers, place an in-line trap between the pump and the impinger to protect the sam- pler from liquid or vapors. The impinger and trap can be mounted to the sampler using the accessory mounting screws (Figure 1, #12) or (cont’d) placed in a holster at the worker’s waist.
-
Page 13: Low Flow Single-Tube Applications
Mode Key SAMPLE PERIOD — MINUTES Setup Key FLOW START BATTERY HOLD CHECK Digit Set/Pump Run Time Key SET-UP MODE AIRCHEK SAMPLER MODEL 224-PCXR8M DIGIT DIGIT SELECT TOTAL PUMP ELAPSED Digit Select/Total Elapsed TIME TIME FLOW Time Key On/Off Switch... - Page 14 Activating the Regulator Remove the tamper-resistant cover. Start the pump using the on/off switch (Figure 1, #8). Press Start/Hold (Figure 1, #3). Press Flow and Battery Check (Figure 1, #2). Adjust the flow using the flow adjust screw (Figure 1, #11) until the built-in rotameter reads 1.5 L/min.
- Page 15 Setting or Verifying Flow Rate For a diagram of the pump, see Figure 1, page 9. 1 Flow Adjust Screw 2 Rubber Sleeve 3 Sorbent Tube Figure 2 Single Adjustable Low Flow Holder with sample tube Connect a single adjustable low flow holder (Figure 2) to the pump intake (Figure 1, #13) using 1/4-inch Tygon tubing.
- Page 16 When the desired flow is set, place the pump in Hold by press- ing Flow and Battery Check. Disconnect the calibrator. Replace the sorbent tube used for setting the flow with a new unexposed sorbent tube for sample collection. (cont’d) Place the appropriate size tube cover over the tube, and screw it into place on the low flow holder.
- Page 17 Sampling For personal sampling, clip the low flow holder to the worker in the breathing zone. Protect sample pump from weather when in use outdoors. Use of any device other than the approved battery pack to power the pump voids MSHA approval. While the LCD displays HOLD, start sam- Clip holder to worker pling by pressing Start/Hold. If a time delay and pump to belt.
-
Page 18: Low Flow Multiple-Tube Applications
For a diagram of the pump, see Figure 1, page 9. Ensure pump is not running. Charge the battery by connecting the charger plug to the sampler charging jack (Figure 1, #22). Ensure that the battery is fully charged before sampling. Do not charge or operate pump from charger in hazardous locations. Charger and battery Charge in fresh air only. pack connected Use only an SKC-approved charger designated for this model to ensure reliable performance and to maintain the SKC warranty. Ensure proper orientation of charging cable before plugging it into the charging jack. Improper orientation/contact will short- circuit the battery. Short-circuiting the battery pack will render it immediately inoperative. - Page 19 Setting or Verifying Flow Rate If performing multiple-tube sampling using an adjustable low flow holder (dual, tri, or quad), the flow rate of the pump must be greater than the sum of the flow rates through the tubes; the flow rate through any one tube cannot exceed 500 ml/min and maximum total combined flow is 1350 ml/min.
- Page 20 When the desired flow is set on the Screw Screw initial tube, place the pump in Hold by pressing Flow and Battery Check. Remove the calibrator from the tube and connect to the exposed end of Figure 4 the next sorbent tube. Press Flow and Cut-away of Tri/Quad Low Battery Check and repeat the flow Flow Holder...
- Page 21 Programming Delayed and Intermittent Sampling To enter Delayed Start Mode: From Hold, press Set-up. Enter the number of minutes delay (up to 9999) before the sampling period begins by pressing Digit Select and Digit Set. Digit Se- lect advances the flashing digit and Digit Set increases the value of the flashing digit.
- Page 22 Sampling For personal sampling, clip the low flow holder to the worker in the breath- ing zone. Protect sample pump from weather when in use outdoors. Use of any device other than the approved battery pack to power the pump voids MSHA approval. While the LCD displays HOLD, start sampling by pressing Start/Hold. If a time delay has been programmed, DE- LAYED START will flash on the LCD Clip holder to worker and and the amount of time remaining until...
- Page 23 This page is intentionally blank.
-
Page 24: Maintenance
* Replace with new O-ring only as needed. Battery Pack Care For proper maintenance of battery packs, SKC offers chargers (see Optional Accessories, page 28) that condition batteries in ≤ 6 hours. Ensure pump is not running during charging. Follow charger instruc- tions. -
Page 25: Replacing Battery Pack
(not shown) Beltclip Back of pump with battery pack sliding out Case grooves Case screw Use of a repaired or rebuilt battery pack voids the SKC warranty and MSHA approval. Do not charge or operate the pump with charger in hazardous loca- tions! Charge in clean air only. Use only an SKC-approved charger and battery pack designed for the MSHA-approved Universal Sample Pump to ensure reliable per- formance and to maintain the SKC warranty and MSHA approval. Use of any device to power the pump other than the approved bat- tery pack voids MSHA approval. MSHA approved for use with SKC Part No. P22434 (4.8 V battery pack) only. Tampering with the battery pack voids the SKC warranty and MSHA approval. -
Page 26: Service Policy
The Service Department will contact nonwarranty customers with an estimate before proceeding with repairs. Note: SKC Inc. will accept for repair any SKC product that is not contaminated with hazardous materials. Products determined to be contaminated will be returned unser-... - Page 27 This page is intentionally blank.
-
Page 28: Parts Descriptions
Parts Descriptions Use only SKC-approved parts to ensure reliable performance and intrinsic safety and to maintain the SKC warranty. See page 25 for drawing. Description . 1. LCD indicates all sampler functions. . 2. FLOW AND BATTERY CHECK Key allows flow rate setting and battery condition testing. - Page 29 224-PCXR8M Sample Pump See page 24 for parts listing. AIRCHEK SAMPLER SAMPLE PERIOD — MINUTES FLOW START BATTERY HOLD CHECK SET-UP MODE AIRCHEK SAMPLER MODEL 224-PCXR8M DIGIT DIGIT SELECT TOTAL PUMP ELAPSED TIME TIME FLOW FRONT BACK...
-
Page 30: Replacement Parts
Replacement Parts See drawings on page 27. Pump Case Parts P21411 Case Parts (Excluding Battery Case) P22434 Battery Pack Assembly P22417BC Belt Clip with screws P22433P Keyboard Assembly P22433R Cap Screws (set of 2) P22433U Control Board P22433RS2 Replacement Stack (with pressure switch) - does not include flowmeter and filter housing assemblies or motor Pump Stack Parts P22417D... - Page 31 See page 26 for replacement parts listing. P22433P P22433R P22433U P21411 P22434 P22433RS2 does not include P22417BC flowmeter and filter housing assemblies or motor Pump Case Parts P22417J P22417K P22433L P22417D P22417F P22433RS2 P22417G does not P22417H include flowmeter and filter housing assemblies or P22417E...
-
Page 32: Optional Accessories
224-29B 150 mm long 224-29C 220 mm long 224-29D 115 mm with tandem trap tube cover 224-29T Battery Maintenance: Cat. No. PowerFlex Charging System for SKC Personal Pumps 5-station, 100-240 V 223-1000 Single, 120 V 223-2000 Single, 100-240 V 223-2000B PowerFlex Cable for Universal XR (4-cell, MSHA) 223-1003... -
Page 33: Warranty
5. In the event of a defect, malfunction, or other failure of the instrument not caused by any misuse or damage to the instrument while in possession of the buyer, SKC Inc. will remedy the failure or defect without charge to the buyer. The remedy will consist of service or replacement of the instrument.
