EKKO EP30A Manual page 9

Model
Power unit
Operation
Rated Traction weight
Load centre
Axle centre to fork face
Wheelbase
Service weight with battery
Wheels type
Driving wheel size
Bearing wheel size
Additional wheels (dimensions)
Wheels, number front/rear (x = driven)
Track width
Lift
The height of handle in the operation position
Lowered fork height
Overall Length
Length to fork face
Overall Width
Fork dimensions
Outside Width of forks
Min. Ground clearance
Aisle width with pallet 1000 x 1200 across forks
Aisle width with pallet 800 x 1200 along forks
Min. Turning radius
Travel speed, laden/unladen
Lifting speed, with/without load
Lowering speed, with/without load
Maximum climbing ability, with/without load
Service brake
Drive motor
Lift motor
Battery according to DIN 43531/35/36 A,B,C,no
Battery voltage/rated capacity
Battery weight (± 5%)
Type of drive control
Noise level at operator's ear
Steering type
Q (lbs)
c (Inch)
x (Inch)
y (Inch)
lbs
Φ×w(Inch)
Φ×w(Inch)
Φ×w(Inch)
b (Inch)
11
h3 (Inch)
h (Inch)
14
h (Inch)
13
l (Inch)
1
l2 (Inch)
b / b (Inch)
1 2
s/e/l (Inch)
b5 (Inch)
m (Inch)
2
Ast (Inch)
Ast (Inch)
Wa (Inch)
(km/h)
(mm/s)
(mm/s)
(%)
(kW)
(kW)
(V/Ah)
(lbs)
(dB(A))
4
EP30A
Electric
Walkie
6600
23.6
40.79
67.72
1720
PU
Φ9.84×2.95
Φ3.23×6.5
Φ4.88×2.36
1x+2/2
25.2/17.91
9.17
36.6/52.76
3.26
88.58
40.55
35.83
2.36/9.06/48.03
26.97
0.905
96.46
100.39
81.34
7.5/8
42/65
36/30
5/15
Electromagnetic
3
2.2
no
24/280
550
AC
≤70
EPS
