  • Page 1 504S 504s-gb-03.pdf...

  • Page 2: Three Year Warranty

    Declarations When this pump unit is used as a stand alone pump it complies with: Machinery Directive Declaration of 98/37/EC EN60204-1, Low Voltage Directive 73/23/EEC EN61010-1, EMC Directive 89/336/EEC conformity EN50081-1/EN50082-1. When this pump unit is to be installed into a machine or is to be assembled with other Declaration of machines for installations, it must not be put into service until the relevant machinery has been Incorporation...

  • Page 3: Installation

    Installation The 504S/RL is suitable for single phase mains electricity supplies only. To ensure correct lubrication of the gearbox the pump should be run only while its feet are standing on a horizontal surface. The pump should be positioned to allow a free flow of air around it.

  • Page 4: Manual Operation

    The pumphead can be run clockwise for extended tube life, or anti-clockwise to operate against higher pressures. Flow rates Flow rates for the 504S were obtained using silicone tubing with the pumphead rotating clockwise, pumping water at 20C with zero suction and delivery pressures. For critical applications determine flow rates under operating conditions.

  • Page 5: Tube Loading

    Installation Remove the grub screws on the drive front panel to enable the pumphead to be fitted. Fit the track in any one of three orientations, over the drive shaft and locating boss. Secure the track with the locating screw. Ensure the drive shaft is degreased before locating the rotor onto the shaft via the split collet.

  • Page 6: Roller Adjustment

    Roller adjustment The 501RL has a factory set gap of 2.6mm between the rollers and the track and is suitable for tubing having wall thicknesses of between 1.6 and 2.0mm. Adjustment of the gap will be required if tubing having a wall thickness of less than 1.6mm is required. There is an adjusting screw on each of the two roller arms, and each of these screws will require adjustment.

  • Page 7: Drive Spares

    Drive spares Number Spare Spare 12-24V Description GR 0028 GR 0028 Cable gland FH 0007 FH 0010 Fuse holder FS 0003 FS 0043 Fuse 1A T type glass MR 0669S MR 0669S Window cover MR 0771S MR 0771S Window gasket MN 0488S MN 0488S Front/rear panel gasket...
  • Page 8 Outline dimensions...
  • Page 9 Tube number Tube bore Double-Y Maximum cassettes English Pressure (+) Suction Clockwise (rpm) Anticlockwise (rpm) Stop English 501RL, 501RL2 (ml/min) Flow rates " 1/50 1/32 1/16 3/16 5/16 1400 2200 505L (ml/min) Flow rates " 1/16 3/16 5/16 1540 1980 2750 505BA (ml/min) Flow rates...
  • Page 10 313/314 (ml/min) Flow rates " 1/50 1/32 1/16 3/16 5/16 1100 Maximum number of pumpheads 313/314 Peroxide/ Platinum Silicone (0 = bar = 0.5) (0.5 = bar = 2.0) " 1/50 1/32 1/16 3/16 5/16 1/50 1/32 1/16 3/16 5/16 313/314 Marprene, Tygon, Neoprene, Viton (0 = bar = 0.5) (0.5 = bar = 2.0)
  • Page 11 501RL, 501RLG, 313 Product codes Peroxide Silicone Platinum Silicone Marprene Bioprene " 910.0005.016 913.0005.016 902.0005.016 903.0005.016 1/50 1/32 910.0008.016 913.0008.016 902.0008.016 903.0008.016 1/16 910.0016.016 913.0016.016 902.0016.016 903.0016.016 910.0032.016 913.0032.016 902.0032.016 903.0032.016 3/16 910.0048.016 913.0048.016 902.0048.016 903.0048.016 910.0064.016 913.0064.016 902.0064.016 903.0064.016 5/16 910.0080.016 913.0080.016...
  • Page 12 505L, 505LG Product codes (2.4mm) Peroxide Platinum Marprene STA-PURE Gore " Silicone Silicone fluoroelastomer 1/16 910.E016.024 913.E016.024 902.E016.024 960.E032.K24 965.E032.K24 910.E032.024 913.E032.024 902.E032.024 960.E032.K24 965.E032.K24 3/16 910.E048.024 913.E048.024 902.E048.024 960.E048.K24 965.E048.K24 ¼ 910.E064.024 913.E064.024 902.E064.024 960.E064.K24 965.E064.K24 910.E080.024 913.E080.024 902.E080.024 960.E080.K24 965.E080.K24 5/16...
  • Page 13 Product use and decontamination declaration In compliance with the UK Health & Safety at Work Act and the Control of Substances Hazardous to Health Regulations you, the user are required to declare the substances which have been in contact with the product(s) you are returning to Watson-Marlow or any of its subsidiaries or distributors.
