User Manual, SecureHead USB and UART Interface

2. SPECIFICATIONS

General
Card Speed
Electrical
• UART
Power
I/O Voltage Range
Current
• USB
Power
I/O Voltage Range
Current
ESD
Communication interface
• UART
o Baud Rate – 9,600 bits/second as default
o Data bits – 8
o Stop bits – 1
o Parity – None
o Supports Xon-Xoff software handshaking
• USB
o Complies with USB 2.0 specification
Environment
Operating Temperature
Storage Temperature
Humidity
Mechanical
Weight
Copyright © 2010-2020, International Technologies & Systems Corporation. All rights reserved.
3 to 75 ips (7.6 to 190.5 cm/s)
3.0 to 3.6 VDC
2.7 to 3.6 VDC
Active Power Supply Current
Standby Power supply Current
5.0 VDC +/- 10%
2.7 to 3.6 VDC
Active Power Supply Current
Standby Power supply Current
+4kV discharge to head can
-40 °C to 70 °C
-40 °C to 70 °C
-10% to 90% non-condensing
5.67 grams
Page 6 of 76
5 mA
2 mA
7 mA
5 mA
