1. Introduction

ID TECH iMag is a snap-on, magnetic stripe reader designed to work with iPhone and iPod Touch. The
iMag Pro works with all Apple mobile devices including the iPad. The reader delivers a superior
reading performance because of its ability to encrypt sensitive card data. The data encryption process
prevents card holder information from being accessed when the data is stored or in transit, so the
data remains secure from beginning until end.
The reader fully supports TDES and AES data encryption using DUKPT key management method.

2. Features

Compact for comfort and mobility
No external power supply required
Mini USB port enables charging Apple devices with external cable
Bi-directional card reading
Reads encoded data that meets ANSI/ISO/AAMVA standards and some custom formats such
as ISO track 1 format on track 2 or 3
Reads up to three tracks of card data
Provides clear text confirmation data including card holder's name and a portion of the PAN
as part of the Masked Track Data

3. Specifications

Communication Interface:
Power Consumption:
Magnetic Stripe Reader:
Operating Life:
Operating Environment:
Storage Environment:
Dimensions:
UART
5mA during card swipe, less than 1mA when idle
3 track bi-directional reading capabilities
100,000 cycle minimum
0 °C to 55 °C (32 °F to 131 °F) non -condensing
-30 °C to 70 °C ( -22 °F to 158 °F) non -condensing
iMag: 95 mm (L) x 30 mm (H) x 71 mm (W)
iMag Pro: 59mm (L) x 14 mm (H) x 32 mm (W)
iMag Pro II: 59.2mm(L) x 13.1mm(H) x 32.6mm(W)
iMag, iMag Pro (II) User Manual
Page | 5
