User Manual, SecureHead USB and UART Interface
Interface cable and connector
• USB
o Cable connector: Molex 51021-0500 or equivalent
o Standard cable length is 125mm +/- 6.4mm
o Pin Out Table
J1
1
2
3
4
5
• UART
o Cable connector: Molex 51021-0500 or equivalent
o Standard cable length is 125mm +/- 6.4mm
o Pin Out Table
J1
1
2
3
4
5
Copyright © 2010-2020, International Technologies & Systems Corporation. All rights reserved.
Color
Signal
Red
VBUS
White
-DATA
Green
+DATA
Black
GND
Violet
HEAD_CASE
Color
Signal
Violet
HEAD_CASE
White
RX
Yellow
TX
Red
3V
Black
GND
Page 7 of 76
