IDTECH 80140502-001 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
80140502-001
User Manual
Spectrum Pro
PCI PTS 4.X Hybrid Insert Reader
USB / RS232 Interface
80140502-001
Rev. A 5/17/2017
International Technologies & Systems Corporation
10721 Walker Street, Cypress, CA 90630-4720; Tel: (714) 761-6368; Fax: (714) 761-8880
www.idtechproducts.com

Advertisement

Table of Contents
loading

Related Manuals for IDTECH 80140502-001

Summary of Contents for IDTECH 80140502-001

  • Page 1 80140502-001 User Manual Spectrum Pro PCI PTS 4.X Hybrid Insert Reader USB / RS232 Interface 80140502-001 Rev. A 5/17/2017 International Technologies & Systems Corporation 10721 Walker Street, Cypress, CA 90630-4720; Tel: (714) 761-6368; Fax: (714) 761-8880 www.idtechproducts.com...
  • Page 2 Spectrum Pro User Manual Copyright © 2017 ID TECH. All rights reserved. ID TECH 10721 Walker St. Cypress, CA 90630 support@idtechproducts.com Visit: http://www.idtechproducts.com This document, as well as the software and hardware described in it, is furnished under license and may be used or copied online in accordance with the terms of such license. The content of this document is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by ID TECH.
  • Page 3 Spectrum Pro User Manual Revision History Revision Date Description of Changes 2/23/2015 Preliminary Version 3/10/2015 Revise low power mode 10/27/2015 Expanded description of Features and Benefits Default sleep timeout value is 120 seconds 5/17/2017 Update status LED table, add low-power mode details, correct various items.

  • Page 4: Table Of Contents

    Spectrum Pro User Manual Table of Contents INTRODUCTION ..........................5 FEATURES AND BENEFITS ........................ 5 ABBREVIATIONS..........................5 APPLICABLE DOCUMENTS ....................... 6 FRONT AND BACK VIEW ........................6 SPECIFICATIONS ..........................7 ..........................7 UPPLY POWER ..................... 8 ELIABILITY AND NVIRONMENT ........................9 NVELOPE RAWING ...................

  • Page 5: Introduction

    Spectrum Pro User Manual 1. Introduction Spectrum Pro is a PCI PTS 4.X and SRED certified outdoor hybrid insert reader which can read both magstripe cards and chip cards. Meeting the latest requirements of the payment industry, the Spectrum Pro is EMV Level 1 and Level 2 approved, and features DUKPT key management with Triple DES (TDES) encryption to ensure MagStripe and Smart card data will always be protected.

  • Page 6: Applicable Documents

    Spectrum Pro User Manual 4. Applicable Documents ISO/IEC 7813 – Identification cards, Physical Characteristic ISO/IEC 7811 – Identification cards, Recording Techniques, Magnetic Stripe 80140505-001 – ID Tech Spectrum Pro Low Level API Manual 5. Front and Back View Copyright © 2017, International Technologies & Systems Corp. All rights reserved. Page 6 of 15...

  • Page 7: Specifications

    Spectrum Pro User Manual 6. Specifications 6.1 Supply power Supply voltage:  DC 5V without supporting latch  Additional DC 12V to support latch if latch is needed Operating current o Idle – 100mA o Max – 120mA USB suspend current: 200 uA Sleep mode current: 20 uA Stop mode current: ...

  • Page 8: Reliability And Environment

    Spectrum Pro User Manual 6.2 Reliability and Environment  Reliability Magnetic Head Life: 1,000,000 passes minimum Rail and Cover Life: 1,000,000 passes minimum  Environmental Temperature range: Operating: -13º F to 158º F ( -25º C to 70º C) non-condensing Storage: -40º...

  • Page 9: Envelope Drawing

    Spectrum Pro User Manual 6.3 Envelope Drawing Copyright © 2017, International Technologies & Systems Corp. All rights reserved. Page 9 of 15...

  • Page 10: Rs232 Communication Settings

    Spectrum Pro User Manual 6.4.1 RS232 Communication Settings Parameter Specification Transmission protocol Asynchronous Communication method Full Duplex Start bit l bit Data length 8 bits (Bit7: MSB, Bit0: LSB) Parity None Stop bit l bit Transmission speed 115200 bps (default) (Baud rate) Copyright ©...

  • Page 11: Mounting Instructions

    Spectrum Pro User Manual 7. Mounting Instructions The reader can be mounted in either a horizontal or vertical orientation. The removal detection points must be pressed down when the unit is mounted. Please refer to the mounting drawing below. Copyright © 2017, International Technologies & Systems Corp. All rights reserved. Page 11 of 15...

  • Page 12: Led Management

    Spectrum Pro User Manual 8. LED Management There are two LEDs. One is the user-interface LED on the front bezel of the reader; the other (diagnostic) LED is on the back. 8.1 Front LED Status  The LED turns green in idle waiting. ...
  • Page 13 Spectrum Pro User Manual Green Amber State Indicating Service action Check the power cable and power No external power supply Power is on, but Dismount the device Solid firmware(either K21 or MaxQ) and send it back to doesn't run the manufacture. Check that the Solid amber normally means removal detection...
  • Page 14 Spectrum Pro User Manual Check removal Flashing switch if they are Amber fully engaged and Removal flag on and call service center to communicating with its host reactivate the reader. Reader has no communication with its host, and the crypto Solid driver is not functioning: Amber...

  • Page 15: Operation Procedure

    Spectrum Pro User Manual 9. Operation Procedure A chip card should be inserted with chip side facing up (as shown below). A magstripe card should be inserted with magstripe facing down and to the right side of the reader. Please see pictures below. Copyright ©...
