Current Probe (100A)
1.
Jaw Assembly
2.
Trigger
3.
Range Selector
4.
6 pin mini DIN connector
NOTE: To choose the 100A current probe, press the SETUP button to select CLAMP. When the
CLAMP is reverse video, press the ▲ or ▼ button to select 100.
Current Probe (1000A)
1.
Jaw Assembly
2.
Trigger
3.
Range Selector
4.
6 pin mini DIN connector
NOTE: To select the1000A current probe, press the SETUP button to select CLAMP. When the
CLAMP is reverse video, press the ▲ or ▼ button to select 1000.
100A
100A
(HARMON)
100A
(POWER)
60A
10A
(HARMON)
10A
1A
1A
1000A
100A
10A
9
