Flexible Current Probe (3000A)
NOTE: The flexible current probe has a maximum input of 3000A however the maximum input
current of the 382095 Power and Harmonics Analyzer is 1000A.
1.
Control Box
2.
Output Range Select Switch
3.
Flexible Loop
4.
Coupling Assembly
NOTE: To select the 3000A flexible current probe, press the SETUP button to select CLAMP. When
the CLAMP is reverse video, press the ▲ or ▼ button to select 3000.
10
382095 V4.1 7/06
